1762-L24BXB Allen-Bradley MicroLogix 1200 Datasheet & Technical Manual
$123.00
$320.00
Description
Allen-Bradley 1762-L24BXB MicroLogix 1200 Programmable Logic Controller
Configured for discrete signal processing and serial communication execution in MicroLogix 1200 control systems, the Allen-Bradley 1762-L24BXB (1762-L24BXB Programmable Controller) provides direct physical/electrical execution through 24 VDC inputs, relay/FET outputs, and embedded serial protocols.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 1762-L24BXB |
| Brand | Allen-Bradley / Rockwell Automation |
| Origin | United States |
| Weight | 0.99 lbs |
| Dimensions | 34 cm x 19 cm x 16 cm |
| Operating Temp | 0 to 55 deg C |
| Power Consumption | 40 W |
| Product Type | Programmable Logic Controller (PLC) |
| Series | MicroLogix 1200 |
| Power Supply | 24 VDC |
| Digital Inputs | 10 x 24 VDC standard inputs; 4 x fast 24 VDC inputs |
| Input Circuit Type | 24 VDC sink/source |
| Digital Outputs | 5 relay outputs; 4 standard 24 VDC FET outputs; 1 high-speed 24 VDC FET output |
| Output Circuit Type | Relay and FET |
| Relay Contact Rating | 24-125 VDC; 120-240 VAC |
| Communication Port | 1 x 8-pin mini-DIN serial port |
| Communication Protocols | DF1, DH-485, ASCII, MODBUS |
| Operating Frequency | 0-20 kHz |
| Mechanical Cycles | 20,000,000 |
| Power Supply Output | 350 or 400 mA |
Industrial Control and Communication Features
The 1762-L24BXB controller provides I/O density scaling through mixed digital input and output configurations. The embedded serial communication interface supports DF1, DH-485, ASCII, and MODBUS protocols for connection with compatible programming terminals and industrial communication networks.
The controller supports EtherNet/IP deterministic networks through compatible external communication modules when system expansion is required. The MicroLogix 1200 architecture uses modular I/O expansion capability and firmware compatibility management for application updates and controller maintenance.
Frequently Asked Questions
Q: What type of communication interface is integrated in the 1762-L24BXB?
A: The controller includes one 8-pin mini-DIN serial communication port supporting DF1, DH-485, ASCII, and MODBUS protocols.
Q: What output configurations are available on the 1762-L24BXB?
A: The controller provides five relay outputs, four 24 VDC FET outputs, and one high-speed 24 VDC FET output.
Q: What is the controller power input requirement?
A: The 1762-L24BXB operates from an external 24 VDC power supply.
Field Installation Guidelines
Install the controller inside an industrial enclosure with suitable protection from dust, moisture, and electrical interference. Verify that the 24 VDC supply wiring polarity matches the controller terminal requirements before power application.
Separate communication wiring from high-current switching circuits and relay output conductors to reduce electrical noise coupling. Apply cabinet grounding practices for signal cable shields and maintain proper routing between field I/O wiring and serial communication cables.
Confirm input device voltage compatibility and output load characteristics before connecting field equipment. Ensure that FET outputs are used within their specified switching conditions and that relay contacts are applied within the rated voltage and current limits.
