ABB 1TNE968902R2201 DO561 Digital Output Module
$258.00
$520.00
Description
Overview
The DO561 (1TNE968902R2201) is a high-performance digital output module designed for ABB Advant OCS and Symphony Plus distributed control systems (DCS). Engineered for reliable operation in demanding industrial environments, it delivers precise and isolated output signals to field devices including relays, solenoids, and actuators.
Key Features
-
8 digital output channels with transistor outputs
-
Galvanic isolation between outputs and system bus
-
LED indicators for channel status and fault detection
-
Compact and lightweight design (135 × 74 × 34 mm, ~0.118 kg)
-
Wide operating temperature range: 0°C to +60°C
-
IP20 protection for industrial environments
-
CE, RoHS, and REACH compliant
Technical Specifications
| Specification | Details |
|---|---|
| Module Model | DO561 |
| Part Number | 1TNE968902R2201 |
| Output Channels | 8 Digital Outputs |
| Output Type | Transistor |
| Output Voltage | 24 V DC nominal (20.4–28.8 V DC) |
| Output Current | Up to 0.5 A per channel |
| Supply Voltage | 20.4–28.8 V DC |
| Isolation | Galvanic isolation between outputs and system bus |
| Connection | Pluggable terminal blocks |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Dimensions (L×H×W) | 135 × 74 × 34 mm |
| Weight | 0.22 kg |
| Protection Class | IP20 |
Applications
-
Control of pumps, valves, and actuators in process plants
-
Binary output management in power generation systems
-
Machinery control in manufacturing lines
-
Infrastructure systems for utilities and transportation
FAQ
Q: Can this module be used outside ABB DCS systems?
A: No, the DO561 is specifically designed for ABB Advant OCS and Symphony Plus systems. Compatibility with other platforms is not guaranteed.
Q: What is the difference between transistor and relay output variants?
A: Transistor outputs provide fast switching and low power consumption, whereas relay outputs are suitable for higher voltage or current loads. Ensure the correct variant is selected for your application.
Q: How are diagnostics handled?
A: Each channel features status LEDs and fault detection to quickly identify wiring or device issues.
Features
Minimum Order Quantity (MOQ)
We welcome bulk orders and have a minimum order quantity of just one unit.
Certificates and Documentation
Upon request, we can provide all necessary documentation, including Certificates of Origin/Conformance and other required export documents.
Delivery Time
For items in stock, we aim to deliver within 1-3 days after payment confirmation. Items with specified lead times will be delivered according to the quoted schedule.
Payment Methods
We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% due before shipment. For RMB transfers, please contact us if you have an agent in China.
Warranty
We offer a standard one-year warranty on all new and original items. If you require an extended warranty, please contact us for additional cost details.
Refund and Return Policy
Your satisfaction is important to us. If you need to return an item, it must be done within 30 days of the order date. The product must be unused, unopened, and in its original packaging with all accessories included. Refunds are processed within 5-7 business days after we receive the returned item. Please note that shipping and related charges are non-refundable.
