ABB 3BHE014105R0001 5SHY3545L0020 5SXE080166 IGCT Module
$258.00
$520.00
Description
Overview
The ABB 3BHE014105R0001 5SHY3545L0020 5SXE080166 is a high-power semiconductor module engineered for robust performance in generator excitation, HVDC converters, and heavy-duty industrial drives. Its press-pack design ensures superior mechanical integrity, thermal reliability, and long-term switching stability, making it a critical component in power generation and industrial energy conversion systems.
Technical Specifications
| Attribute | Specification |
|---|---|
| Manufacturer | ABB |
| Model / Part Numbers | 3BHE014105R0001 5SHY3545L0020 5SXE080166 |
| Module Type | IGCT Module |
| Rated Voltage (VCES) | 3300 V |
| Rated Current (IC) | 1800 A @ 90 °C |
| On-State Voltage Drop | ≤ 1.5 V (typical) |
| Switching Energy Loss | Eon ≤ 650 mJ / Eoff ≤ 550 mJ @ 1500 V / 1800 A |
| Thermal Resistance (Junction-Case) | Rth = 0.015 K/W |
| Isolation Voltage | 12 kV AC, 1 min (50 Hz) |
| Operating Junction Temp. | -40 °C to +150 °C |
| Integrated Monitoring | NTC 10 kΩ temperature sensor, ±1 °C accuracy |
| Package Dimensions | Press-Pack S4, 122 × 140 × 38 mm |
| Certifications | UL 1557, IEC 60747-9 |
| Typical Applications | HVDC transmission, synchronous generator excitation, marine propulsion, industrial heavy-duty drives |
Key Features
-
High voltage and current capacity for demanding power conversion
-
Press-pack construction for mechanical and thermal robustness
-
Integrated temperature sensor enables precise thermal monitoring and protection
-
Low conduction and switching losses optimize efficiency
-
Wide operating temperature range supports harsh industrial environments
-
International safety and performance certifications ensure reliable deployment
Applications
The module is designed for integration into high-power systems such as HVDC transmission links, synchronous generator excitation units, large industrial drives, and marine propulsion converters. Its press-pack IGBT/IGCT configuration allows seamless operation under heavy-duty cyclic loads and high-current pulses.
FAQ
Q: What distinguishes the press-pack IGBT/IGCT from standard modules?
A: Press-pack modules provide enhanced mechanical stability, uniform current distribution, and superior thermal cycling reliability, reducing the risk of chip fracture under high stress.
Q: Can this module operate in marine environments?
A: Yes, the wide temperature range and certified insulation make it suitable for marine propulsion and offshore power applications.
Q: Are there similar models for comparison?
A: ABB’s 3BHE014105R0001 shares functional similarities with the 3BHE014106R0001 module, offering slightly different current ratings and thermal performance for specialized applications.
