ABB TP858 3BSE018138R1 Module Base
$258.00
$520.00
Description
Product Description
The ABB TP858 3BSE018138R1 module base is a dedicated mounting and interface platform engineered for the TP858 operator panel used in the Symphony Plus distributed control system (DCS). It serves as the physical and electrical integration point between the operator interface and the system cabinet, ensuring stable installation, reliable power delivery, and communication connectivity.
Designed for demanding industrial control environments, the module base provides structured wiring interfaces, Ethernet communication pathways, and secure panel mounting. When paired with the TP858 HMI, the assembly offers a protected operator interface with industrial-grade sealing and dependable network access to the Symphony Plus control infrastructure.
The TP858 3BSE018138R1 base simplifies cabinet installation and helps maintain system reliability in power generation and process automation applications.
Technical Specifications
| Specification | Details |
|---|---|
| Model | TP858 3BSE018138R1 |
| Brand | ABB |
| Product Type | Operator Panel Module Base |
| Compatible Device | TP858 Operator Panel |
| Control System | Symphony Plus DCS |
| Power Input | 24 V DC distributed via base connections |
| Network Interface | Dual Ethernet ports for redundant communication |
| System Connectivity | Internal system bus and interface connectors |
| Mounting Method | DIN rail or cabinet backplate installation |
| Protection Rating | IP65 front protection when panel is mounted |
| Operating Temperature | -10°C to +55°C |
| Dimensions | 350 × 280 × 60 mm |
| Weight | 0.5 kg |
Key Functional Characteristics
Mechanical Integration
The module base provides rigid mounting support for the TP858 operator interface within industrial control cabinets, helping maintain stability under vibration and temperature fluctuations.
Integrated Power Distribution
Power supplied through the base is routed directly to the connected operator panel, minimizing external wiring and simplifying cabinet layout.
Redundant Communication Connectivity
Dual Ethernet interfaces support network redundancy, improving availability for critical control systems within Symphony Plus architectures.
Simplified Installation
The design supports fast installation on DIN rails or cabinet mounting plates, reducing integration time during system commissioning or maintenance.
Industrial Environmental Protection
When the TP858 panel is installed, the assembly achieves a sealed front interface suitable for harsh plant environments requiring IP65 protection.
Typical Application Environments
Power generation plants including turbine and boiler control rooms where Symphony Plus operator stations are deployed.
Oil and gas processing facilities requiring reliable human-machine interfaces integrated with distributed control systems.
Heavy industrial sectors such as steel, cement, and chemical production where robust operator panels are required.
Water treatment plants and utility infrastructure that depend on reliable plant-wide monitoring and control interfaces.
FAQ
What is the function of the TP858 module base in a Symphony Plus system?
It provides the mechanical mounting structure and electrical interface required to install and operate the TP858 operator panel within the control cabinet.
Is the TP858 base compatible with other operator panels?
No. It is specifically designed for the TP858 HMI panel used in the ABB Symphony Plus control platform.
Does the base include communication interfaces?
Yes. It supports Ethernet connectivity and internal system bus connections to enable communication between the operator interface and the control network.
