Allen-Bradley 1440-TPS02-01RB XM-320 Position Module
$123.00
$320.00
Description
Overview
The Allen-Bradley 1440-TPS02-01RB XM-320 module is a dual-channel position and process monitoring unit engineered for predictive maintenance and machinery protection applications. Designed for integration within the XM condition monitoring platform, this module continuously measures shaft position, casing movement, and vibration signals from rotating machinery.
Equipped with DeviceNet communication capability and analog output functionality, the module enables reliable real-time data transmission to supervisory control and monitoring systems. Its compact DIN rail mounting design allows efficient installation in industrial control cabinets and machine protection systems.
Key Features
-
Dual-channel position monitoring architecture
-
Supports shaft displacement and vibration measurement
-
Integrated DeviceNet communication interface
-
RS-232 serial communication port for configuration and diagnostics
-
Two isolated 4–20 mA analog outputs
-
DPDT relay control output for alarms and trip functions
-
Designed for continuous machinery condition monitoring
-
Compatible with Allen-Bradley XM series monitoring systems
-
Compact terminal-base mounting structure
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Series | XM Series |
| Model | 1440-TPS02-01RB |
| Functional Type | XM-320 Position Measurement Module |
| Number of Channels | 2 Channels |
| Input Power | 24 VDC |
| Current Consumption | 200 mA |
| Power Consumption | Approx. 5.28 W |
| Analog Outputs | 2 × 4–20 mA |
| Relay Output | 1 DPDT Control Relay |
| Communication | DeviceNet, RS-232 |
| Operating Temperature | -20°C to +65°C |
| Mounting Method | Terminal Base Mounting |
| Application Type | Position & Process Monitoring |
| Weight | 0.51 lbs |
Applications
The 1440-TPS02-01RB module is commonly deployed in industrial rotating equipment monitoring systems, including:
-
Steam and gas turbines
-
Pumps and compressors
-
Motors and generators
-
Gearboxes
-
Fans and blowers
-
Process machinery with critical rotating components
It is suitable for facilities implementing predictive maintenance strategies and continuous vibration analysis.
Communication & Monitoring Capability
This XM-320 monitoring module supports DeviceNet network integration, enabling communication with PLC and SCADA systems for centralized diagnostics and alarm management. The onboard RS-232 interface simplifies commissioning, parameter setup, and maintenance troubleshooting.
The integrated relay output can be configured for alarm annunciation or machine shutdown protection based on process thresholds.
FAQ
What does the XM-320 module monitor?
The module monitors shaft position, casing vibration, pedestal movement, and other process-related displacement signals in rotating equipment.
Does the module support analog signal output?
Yes. The unit provides two independent 4–20 mA analog outputs for integration with external monitoring or control systems.
What communication protocol is supported?
The module supports DeviceNet communication and includes an RS-232 serial interface for local configuration.
Is the 1440-TPS02-01RB suitable for machine protection systems?
Yes. Its relay output and continuous monitoring functions make it suitable for machinery protection and predictive maintenance applications.
