Allen-Bradley 1492-CM1771-LD006 1492 I/O Wiring Conversion System Swing-Arm Conversion Module
$123.00
$320.00
Description
Allen-Bradley 1492-CM1771-LD006 1492 I/O Wiring Conversion System Swing-Arm Conversion Module
Configured for analog input migration in Allen-Bradley PLC conversion systems, the Allen-Bradley 1492-CM1771-LD006 (1492-CM1771-LD006 swing-arm conversion module) provides direct electrical execution between legacy 1771 swing-arm terminations and ControlLogix 1756 analog input assemblies. The module preserves existing field-side wiring paths while redirecting signal termination to compatible 1756 removable terminal blocks.
Suffix Breakdown & Model Matrix
| Model Variant | Description |
|---|---|
| 1492-CM1771-LD006 | Swing-arm conversion module |
| Legacy Module Compatibility | 1771-IFE analog input module |
| ControlLogix Compatibility | 1756-IF8 analog input module |
| Conversion Method | Existing swing-arm field wiring retention |
| Interface Wiring | Pre-wired 1492 conversion cables |
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 1492-CM1771-LD006 |
| Brand | Allen-Bradley |
| Origin | United States |
| Product Type | Swing-Arm Conversion Module |
| Series | 1492 I/O Wiring Conversion System |
| Compatible Legacy Modules | 1771-IFE |
| Compatible ControlLogix Modules | 1756-IF8 |
| Conversion Type | Swing-arm conversion |
| Installation | Conversion mounting assembly |
| Wiring Method | Pre-wired 1492 cables to 1756 RTBs |
| Operating Temp | 0 deg C to +60 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Relative Humidity | 5% to 95% non-condensing |
| Pollution Degree | 2 |
| Certifications | CE, UL, C-UL-US, FM |
| Weight | 0.4 lbs |
| Power Consumption | Passive conversion module; no internal power consumption |
| Lifecycle Status | Active |
EtherNet/IP Signal Transition and Firmware Compatibility
The 1492-CM1771-LD006 is intended for staged migration from PLC-5 analog input infrastructures to ControlLogix analog acquisition platforms without removal of existing field terminations. The conversion assembly maintains channel continuity between the original swing-arm interface and the target 1756 analog module architecture.
During migration activity, analog signal integrity depends on conductor shielding continuity, RTB seating pressure, and consistent terminal mapping between the 1771 and 1756 addressing structures. The module functions as a passive transition interface and does not perform analog scaling, loop isolation, or signal conditioning. Firmware handling and analog filtering behavior remain dependent on the installed 1756-IF8 module configuration.
