Allen-Bradley 1606-XL240E 1606-XL Switched Mode Power Supply
$123.00
$320.00
Description
Overview
The 1606-XL240E from Allen-Bradley is a compact switched mode power supply engineered for industrial automation and control panel applications. As part of the 1606-XL series, this unit is designed to provide stable DC output power while maintaining high efficiency and flexible installation capability in space-constrained cabinets.
The module accepts a universal AC input range and delivers regulated 24V DC class output power suitable for PLC systems, field devices, sensors, communication equipment, and industrial control components. Its compact housing and DIN rail mounting design simplify panel integration across a broad range of machine control environments.
Key Features
-
Industrial-grade switched mode power supply
-
Compact DIN rail mounting design
-
Adjustable DC output voltage from 24V to 28V DC
-
Rated output power up to 240W
-
High operating temperature tolerance
-
Supports parallel operation for increased system capacity
-
Suitable for continuous industrial operation
-
Global certifications including CE and UL approvals
-
Designed for control cabinets and automation panels
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Model Number | 1606-XL240E |
| Product Series | 1606-XL |
| Product Type | Switched Mode Power Supply |
| Input Voltage Range | 100–240V AC |
| Nominal Input Voltage | 120/230V AC |
| Output Voltage | 24–28V DC Adjustable |
| Preset Output Voltage | 24.5V DC |
| Rated Output Power | 240W |
| Maximum Output Power | 288W Peak |
| Output Current | 10A |
| Overvoltage Protection | 36–39V DC |
| Mounting Method | DIN Rail Mount |
| Parallel Operation Support | Up to 5 Units |
| Operating Temperature | 0°C to 70°C |
| Full Load Operation | Up to 60°C Without Derating |
| Cooling Method | Natural Convection |
| Electrolytic Capacitor Rating | 105°C |
| Certifications | CE, UL |
| Weight | 2.1 lb |
Performance and Design
The 1606-XL240E is designed for stable long-term DC power delivery in industrial environments requiring high reliability and compact installation. The unit can operate continuously at full load up to 60°C ambient temperature without derating, making it suitable for dense control cabinet installations.
Support for parallel operation allows multiple units to be connected for load sharing or redundancy configurations in critical systems.
Typical Applications
Common uses for the 1606-XL240E include:
-
PLC and PAC control systems
-
Industrial automation panels
-
Machine building applications
-
Process control systems
-
Communication and networking equipment
-
Factory power distribution
-
Packaging and conveyor systems
-
Remote I/O power applications
Installation Notes
The module is intended for DIN rail mounting inside industrial electrical enclosures. Adequate airflow spacing is recommended to maintain thermal performance under high-load conditions.
Input protection and grounding should follow applicable electrical installation standards and manufacturer guidelines.
FAQ
What output voltage does the 1606-XL240E provide?
The module provides an adjustable DC output range from 24V to 28V DC, with a factory preset around 24.5V DC.
Can multiple units operate together?
Yes. The 1606-XL240E supports parallel operation with up to five units for redundancy or increased current capacity.
What is the maximum output current?
The power supply delivers up to 10A output current under standard operating conditions.
Is this power supply suitable for high-temperature environments?
Yes. The unit operates at full load up to 60°C without derating and can continue operating up to 70°C with reduced load conditions.
