Allen-Bradley 1756-IT6I ControlLogix Thermocouple Module
$123.00
$320.00
Description
Product Description
The 1756-IT6I is a multi-channel thermocouple and millivolt analog input module designed for the Allen-Bradley ControlLogix platform. This module features six individually isolated input channels and integrated cold junction compensation (CJC), enabling precise temperature acquisition in demanding industrial environments.
Designed for high-accuracy thermal process monitoring, the Allen-Bradley 1756-IT6I supports a broad range of industry-standard thermocouple sensors including B, C, D, E, J, K, L, N, R, S, and T types. The module also accepts low-level millivolt signals for specialized measurement applications.
With 16-bit resolution, isolated channel architecture, and flexible floating-point or integer data processing, the module is suitable for critical temperature monitoring systems where signal integrity and electrical noise immunity are essential.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Series | ControlLogix |
| Product Type | Isolated Thermocouple Analog Input Module |
| Model Number | 1756-IT6I |
| UPC | 10612598172310 |
| Input Channels | 6 Individually Isolated Inputs |
| Additional Sensor Input | 1 Integrated Cold Junction Compensation (CJC) |
| Signal Type | Thermocouple and Millivolt Inputs |
| Supported Thermocouple Types | B, C, D, E, J, K, L (TXK/XK), N, R, S, T |
| Analog Resolution | 16-Bit |
| Standard Millivolt Range | -12 to +78 mV |
| High-Resolution Range | -12 to +30 mV |
| Typical Resolution | 1.4 µV/bit |
| High-Resolution Accuracy | 0.7 µV/bit |
| Data Formats | Integer (2’s Complement), IEEE 32-Bit Floating Point |
| Minimum Scan Time | 10 ms Integer Mode (Millivolt) |
| Floating Point Scan Time | 25 ms (Millivolt), 50 ms (Temperature) |
| Backplane Current at 5.1V DC | 250 mA |
| Backplane Current at 24V DC | 2 mA |
| Total 24V Backplane Load | 125 mA |
| Maximum Power Dissipation | 4.3 W |
| Operating Temperature Range | 0 to 60°C |
| Compatible Terminal Blocks | 1756-TBNH, 1756-TBSH |
| Isolation Type | Channel-to-Channel Isolated Inputs |
| Weight | 0.62 kg |
Key Features
-
Six isolated thermocouple input channels
-
Integrated cold junction compensation for accurate temperature readings
-
Compatible with major industrial thermocouple standards
-
Supports both thermocouple and millivolt signal measurement
-
High-resolution 16-bit analog conversion
-
Floating-point and integer data formatting options
-
Designed for electrically noisy industrial environments
-
Seamless integration with ControlLogix chassis systems
Typical Applications
-
Furnace and kiln temperature monitoring
-
Chemical process control
-
Boiler and steam system automation
-
Heat treatment equipment
-
Food processing systems
-
Power generation facilities
-
Industrial thermal management
-
Oil and gas process instrumentation
FAQ
What sensor types are compatible with the 1756-IT6I?
The module supports thermocouple types B, C, D, E, J, K, L, N, R, S, and T, as well as direct millivolt input signals.
Does the module provide channel isolation?
Yes. Each of the six analog input channels is individually isolated to reduce electrical interference and improve measurement stability.
What is the purpose of the integrated CJC sensor?
The built-in cold junction compensation sensor improves thermocouple accuracy by compensating for terminal temperature variations.
Which terminal blocks can be used with this module?
The module is compatible with Allen-Bradley 1756-TBNH and 1756-TBSH removable terminal blocks.
