Allen-Bradley 1769-ADN DeviceNet Adapter Module CompactLogix
$123.00
$320.00
Description
Product Description
The 1769-ADN DeviceNet adapter module is designed to integrate Compact I/O systems with DeviceNet fieldbus networks. Engineered by Allen-Bradley, this module enables reliable communication between distributed I/O devices and controllers such as CompactLogix and MicroLogix 1500.
With support for multiple baud rates and robust diagnostic capabilities, the module ensures stable data exchange in industrial automation environments. Its compact form factor allows flexible installation in space-constrained control panels.
The 1769-ADN functions as a DeviceNet slave adapter, making it suitable for connecting local Compact I/O racks to a DeviceNet scanner or master device.
Key Technical Features
-
Compatible with CompactLogix and MicroLogix 1500 systems
-
Supports DeviceNet communication speeds: 125 kbps, 250 kbps, and 500 kbps
-
Integrated single DeviceNet communication port
-
Multi-status LED indicators for module, network, I/O, and diagnostics
-
Flexible mounting options: DIN rail or panel installation
-
Open-style enclosure for cabinet integration
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Model Number | 1769-ADN |
| Product Type | DeviceNet Adapter Module |
| Product Series | CompactLogix 1769 |
| Communication Interface | 1 × DeviceNet Port |
| Data Rates | 125 / 250 / 500 kbps |
| Isolation Voltage | 30 V (continuous) |
| Power Consumption | 33.6 W |
| Power Dissipation | 7.5 W |
| Backplane Current | Series A: 450 mA @ 5V DC; Series B: 500 mA @ 5V DC |
| Mounting | DIN Rail or Panel |
| Enclosure Type | Open (IP20 when installed in enclosure) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Weight | 0.38 lb |
| Certifications | UL, CE, ODVA DeviceNet Conformance |
| Power Supply Distance Rating | Series A: 4 modules; Series B: 5 modules |
Application Scenarios
The 1769-ADN module is widely used in distributed control architectures where Compact I/O needs to communicate over DeviceNet. Typical applications include packaging systems, material handling lines, automotive assembly, and process skids requiring decentralized I/O connectivity.
FAQ
What role does the 1769-ADN play in a DeviceNet network?
It operates as a DeviceNet adapter (slave), allowing a Compact I/O rack to be controlled by a DeviceNet master or scanner.
Is this module interchangeable with a DeviceNet scanner?
No. Unlike scanner modules, the 1769-ADN does not control the network; it responds to commands from a master device.
Can it be used in high-vibration environments?
Yes, provided it is properly mounted on a DIN rail or panel within a compliant industrial enclosure.
