Allen-Bradley 1771-IVN PLC-5 DC Input Module
$123.00
$320.00
Description
Product Description
The Allen-Bradley 1771-IVN is a 32-channel digital DC input module engineered for PLC-5 automation systems and Bulletin 1771 I/O chassis platforms. Designed for low-true input operation, this module interfaces with field devices operating within a 10 to 30 Volts DC range and is optimized for applications requiring reliable high-density discrete input processing.
The module supports sourcing-type inputs and is intended for use with sinking field output devices. It features four isolated groups of eight inputs, enabling flexible wiring and signal organization in distributed control architectures. The 1771-IVN operates using half-slot addressing without limitations and can also support single-slot addressing configurations depending on processor and chassis compatibility.
Built for rack-mounted installation, the module communicates directly through the PLC-5 backplane and consumes minimal backplane current, making it suitable for legacy modernization projects and existing 1771-based control systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Series | PLC-5 |
| Model Number | 1771-IVN |
| Product Type | Digital DC Input Module |
| Input Channels | 32 Inputs |
| Input Grouping | 4 Groups of 8 Inputs |
| Input Voltage Category | 10–60V DC Source Input |
| Recommended Operating Voltage | 10–30V DC |
| Input Logic | Low True |
| Input Configuration | Sourcing Inputs |
| Compatible Field Devices | Sinking Outputs |
| Addressing Support | Half-Slot and Conditional 1-Slot |
| 2-Slot Addressing | Not Supported |
| Input Image Table | 32 Bits |
| Output Image Table | None |
| Backplane Current Draw | 280 mA |
| Maximum Off-State Current | 1.7 mA |
| Typical On-State Delay | 6 ms ±2 ms |
| Typical Off-State Delay | 50 ms |
| Mounting Style | Rack Mount |
| Compatible Wiring Arm | 1771-WH |
| Weight | 0.45 kg |
Key Features
-
32-point high-density DC input interface
-
Compatible with PLC-5 and 1771 chassis systems
-
Supports low-true digital input signals
-
Four isolated input groups for flexible wiring
-
Designed for sourcing input applications
-
Half-slot addressing support without restrictions
-
Digital filtering for stable signal processing
-
Rack-mounted industrial module construction
Typical Applications
The 1771-IVN input module is commonly used in:
-
PLC-5 discrete input systems
-
Factory automation panels
-
Conveyor and material handling systems
-
Packaging machinery
-
Motor control monitoring
-
Process control equipment
-
Legacy Allen-Bradley 1771 installations
-
Distributed industrial I/O systems
FAQ
What type of signals does the 1771-IVN accept?
The module accepts low-true DC digital input signals within a recommended operating range of 10 to 30V DC.
Can the 1771-IVN be installed in all 1771 chassis systems?
Yes. The module is compatible with current Allen-Bradley Bulletin 1771 I/O chassis platforms.
Does the module support 2-slot addressing?
No. The 1771-IVN supports half-slot addressing and limited 1-slot addressing only.
What wiring arm is required for installation?
The module uses the Allen-Bradley 1771-WH wiring arm.
Is this module suitable for modern PLC platforms?
The module is primarily designed for PLC-5 and legacy 1771 systems but is still widely used in maintenance and retrofit applications.
