Allen-Bradley 1771-P7B Power Supply Module
$123.00
$320.00
Description
Allen-Bradley 1771-P7B Power Supply Module
The Allen-Bradley 1771-P7B serves as the primary 1771-P7B power supply module utilized to execute chassis power conversion and backplane energization across PLC-5 and 1771 I/O platforms.
Suffix Breakdown & Model Matrix
The supplied documentation identifies the 1771-P7B as a fixed catalog power supply module for PLC-5 and 1771 chassis systems. No configurable suffix matrix or hardware option segmentation is specified in the provided material.
Hardware Specifications
| ParameterSpecification | |
| Model | 1771-P7B |
| Brand | Allen-Bradley |
| Product Series | PLC-5 / 1771 I/O |
| Product Type | Power supply module |
| Input Voltage | 100-240 VAC |
| Input Frequency | 47-63 Hz |
| Input Current | 2.0 A at 120 VAC, 1.0 A at 220 VAC |
| Output Voltage | 24 VDC, 5 VDC |
| Output Current | 10-16 A |
| Power Rating | 240-384 W |
| Efficiency | >85 % |
| Ripple and Noise | <200 mVpp |
| Protection Features | Over-voltage, over-current, short-circuit |
| Mounting Method | DIN rail installation |
| Enclosure Rating | IP20 to IP67 depending on assembly configuration |
| Compatibility | PLC-5, 1771 I/O chassis, Mini-PLC-2 systems |
| Supported Chassis | 1771-A1B, A2B, A3B, A3B1, A4B |
| Operating Temp | -20 to 60 deg C |
| Storage Temp | -40 to 85 deg C |
| Humidity | 5-95 % non-condensing |
| Dimensions | 127 mm x 76 mm x 23 mm |
| Weight | 3.99 lbs |
Backplane Bus Power Distribution Characteristics
The 1771-P7B distributes regulated DC power directly into the PLC-5 and 1771 backplane structure for processor, adapter, and I/O module energization. Internal regulation stages maintain output stability during fluctuating AC input conditions across the specified universal voltage range.
The module supports deterministic backplane power delivery required by PLC-5 rack communication timing and distributed I/O synchronization. Output ripple below 200 mVpp reduces propagation of switching noise into analogue and digital chassis circuitry.
Integrated protection circuitry monitors over-current, over-voltage, and short-circuit conditions within the supply stage. Fault handling limits excessive thermal stress on connected chassis assemblies and attached field-side modules.
