Allen-Bradley 1771-WI PLC-5 Thermocouple Wiring Arm
$123.00
$320.00
Description
Product Description
The 1771-WI terminal wiring arm from Allen-Bradley is a field wiring accessory developed for Bulletin 1771 and PLC-5 I/O systems. This component provides a secure connection interface between field instrumentation and compatible PLC input modules, particularly in thermocouple signal applications.
Designed with 18 terminal connections and support for up to 8 I/O channels, the Allen-Bradley 1771-WI simplifies installation and maintenance within rack-mounted PLC systems. Gold-plated contacts improve signal integrity and minimize connection resistance, making the unit suitable for low-level analog and temperature measurement signals.
The wiring arm features conformal-coated construction for additional protection against moisture, dust, and corrosive industrial environments. It does not require an independent power source and installs directly onto compatible 1771 series modules.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen-Bradley |
| Model Number | 1771-WI |
| Product Family | PLC-5 / Bulletin 1771 |
| Product Type | Wiring Arm |
| Maximum Supported I/O | 8 channels |
| Terminal Count | 18 terminals |
| Typical Application | Thermocouple input wiring |
| Contact Material | Gold-plated contacts |
| Recommended Screw Torque | 7–9 lb-in |
| Protective Coating | Conformal coated |
| External Power Requirement | None |
| Typical AC OFF Delay | 29 ms ±8 ms |
| Typical DC OFF Delay | 30 ms ±7 ms |
| Compatible Wiring Configuration | 1771-WN |
| Installation Type | Rack-mounted module interface |
| Weight | 0.14 kg |
Design Features
The 1771-WI wiring arm is intended for dependable signal termination in PLC-5 control systems where stable analog or thermocouple connections are required.
Primary features include:
-
18-point terminal connection layout
-
Support for up to 8 I/O signal channels
-
Optimized for thermocouple signal applications
-
Gold-plated terminal contacts for improved conductivity
-
Conformal coating for environmental durability
-
Direct integration with Bulletin 1771 modules
-
No separate field power supply required
-
Simplified module replacement and maintenance access
Typical Applications
The 1771-WI is commonly installed in industrial environments involving temperature monitoring and low-level analog signal interfacing.
Common application examples include:
-
Thermocouple input systems
-
Process temperature monitoring
-
PLC-5 analog I/O installations
-
Industrial furnace controls
-
Heat treatment systems
-
Process automation panels
-
Manufacturing temperature supervision
-
Retrofit PLC maintenance projects
FAQ
What is the primary use of the 1771-WI wiring arm?
The 1771-WI is mainly used for thermocouple and low-level signal wiring in PLC-5 and Bulletin 1771 systems.
Does the wiring arm require an external power source?
No. The unit operates without a dedicated external power supply.
How many terminals are included?
The wiring arm provides 18 field wiring terminals supporting up to 8 I/O channels.
Why are gold-plated contacts used?
Gold-plated contacts help reduce signal degradation and improve reliability in sensitive analog and thermocouple applications.
