Allen-Bradley 2711-K10C10 PanelView 1000 Operator Terminal
$123.00
$320.00
Description
Allen-Bradley 2711-K10C10 PanelView 1000 Operator Terminal
Configured for machine visualization and operator command input in ControlNet-connected Allen-Bradley automation systems, the Allen-Bradley 2711-K10C10 (2711-K10C10 PanelView 1000 Operator Terminal) provides direct physical/electrical execution through keypad-based HMI interaction and PLC communication.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 2711-K10C10 |
| Brand | Allen-Bradley / Rockwell Automation |
| Origin | United States |
| Weight | 10.63 lbs |
| Dimensions | 282 x 423 x 112 mm |
| Operating Temp | 0 deg C to 55 deg C |
| Power Consumption | 55 VA maximum |
| Product Series | PanelView 1000 |
| Display Type | Color Active Matrix TFT |
| Display Size | 10.1 in |
| Display Resolution | 640 x 480 pixels VGA |
| Operator Input | Stainless-steel keypad with F1-F16 function keys, numeric and navigation keys |
| Primary Communication | ControlNet communication port |
| Auxiliary Communication | RS-232 printer port |
| Input Voltage | 85-264 VAC, 47-63 Hz |
| Internal Memory | 1008 KB application flash memory |
| Backlight | Replaceable backlight, typical life 50,000 hours |
| Real-Time Clock | Battery-backed clock |
| Enclosure Rating | NEMA 12, 13, 4X indoor use, IP54/IP65 |
Industrial Control Network Integration
The 2711-K10C10 operates as a PanelView Standard terminal within Allen-Bradley ControlNet architectures. The unit exchanges operator commands, status data, and alarm information with connected PLC systems through the dedicated ControlNet interface. The terminal supports legacy automation installations requiring keypad-only operation and RS-232 printer communication.
The hardware design supports Allen-Bradley PLC visualization applications using application files stored in internal flash memory. PCMCIA expansion capability allows additional application storage and transfer functions for configuration management.
Frequently Asked Questions
Q: Does the 2711-K10C10 support touchscreen input?
A: No. The 2711-K10C10 is a keypad-operated PanelView 1000 terminal and uses a stainless-steel keypad with function keys, numeric keys, and navigation controls.
Q: What communication interface is provided for PLC connection?
A: The terminal provides a dedicated ControlNet communication port for connection to compatible Allen-Bradley control systems.
Q: What are the power requirements of this operator terminal?
A: The unit accepts 85-264 VAC input power at 47-63 Hz and has a maximum power consumption rating of 55 VA.
Field Installation Guidelines
Install the terminal in a panel cutout according to the mechanical mounting requirements of the PanelView 1000 enclosure. Maintain separation between communication wiring and high-voltage power conductors to reduce electrical interference.
Connect ControlNet cabling using appropriate industrial grounding and shielding practices. Shield termination should follow the installed network topology requirements. The enclosure grounding connection must be bonded to the panel earth ground to maintain electrical noise control.
Verify AC input wiring polarity, protective grounding, and supply voltage range before energizing the unit. Ensure sufficient clearance around the rear enclosure area for cable routing and maintenance access.
