Allen-Bradley 2711C-T3M PanelView Component HMI Terminal
$123.00
$320.00
Description
Allen-Bradley 2711C-T3M PanelView Component HMI Terminal
Configured for operator visualization and machine control interaction in PanelView Component systems, the Allen-Bradley 2711C-T3M (2711C-T3M HMI Terminal) provides direct physical and electrical execution through a monochrome touchscreen interface and serial communication channels.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 2711C-T3M |
| Brand | Allen-Bradley |
| Origin | Singapore |
| Weight | 0.51 lbs |
| Dimensions | 116 x 138 x 43 mm |
| Operating Temp | 0 deg C to 50 deg C |
| Power Consumption | 5 W maximum |
| Product Type | Graphic Component HMI Terminal |
| Series | PanelView Component C300 |
| Display Size | 3.0 inch |
| Display Type | Monochrome Passive-Matrix STN LCD |
| Resolution | 128 x 64 pixels |
| Operator Input | Analog resistive touchscreen |
| Function Keys | 4 configurable tactile keys (F1-F4) |
| Input Voltage | 24 VDC nominal (18-30 VDC operating range) |
| Memory | 128 MB flash memory / RAM |
| Communication Interface | RS-232 / RS-422 / RS-485 serial port, RS-232 RJ45 port |
| USB Interface | 1 x USB Host Type-A |
| Communication Protocols | DF1, DH-485, Modbus RTU, Modbus Master/Slave, ASCII |
| Ethernet Interface | Not available |
| Enclosure Rating | NEMA 4X indoor use, IP65 |
EtherNet/IP Deterministic Networks and PanelView Firmware Compatibility
The 2711C-T3M belongs to the Allen-Bradley PanelView Component platform and uses serial communication architecture for controller data exchange. The terminal supports RS-232, RS-422, RS-485 interfaces and industrial protocols including DF1, DH-485, Modbus RTU, and ASCII.
The integrated web-based programming environment provides application configuration through a connected PC browser interface. Firmware and application transfer functions are handled through supported communication interfaces and USB Host storage functions. The terminal design supports compact HMI deployment with controller communication through established serial networks.
Frequently Asked Questions
Q: What communication interfaces are available on the 2711C-T3M?
A: The terminal provides serial communication interfaces including RS-232, RS-422, and RS-485 functions, with support for DF1, DH-485, Modbus RTU, and ASCII protocols.
Q: Is the 2711C-T3M equipped with an Ethernet communication port?
A: No. The 2711C-T3M does not include Ethernet hardware. Communication and programming functions are performed through supported serial and USB interfaces.
Q: What type of display and input method are integrated into this HMI terminal?
A: The unit uses a 3 inch monochrome display with an analog resistive touchscreen interface for operator input.
Field Installation Guidelines
Install the terminal into the specified panel cutout and secure the mounting hardware evenly to maintain enclosure sealing performance.
Connect the 24 VDC supply using industrial control wiring practices. Keep DC power conductors separated from high-current switching cables and motor drive wiring to reduce electrical noise coupling.
Use shielded serial communication cables when required by the control system design. Terminate cable shields according to the cabinet grounding method and avoid multiple-point unintended grounding paths.
Verify communication protocol selection, serial parameters, and controller addressing before system startup. Confirm touchscreen calibration, function key assignments, and application loading status after installation.
