Allen-Bradley 2711P-K10C4A2 PanelView Plus 1000 Operator Interface Terminal

Allen-Bradley 2711P-K10C4A2 PanelView Plus 1000 Operator Interface Terminal

The Allen-Bradley 2711P-K10C4A2, also cataloged as the 2711P-K10C4A2 PanelView Plus 1000 operator interface terminal, provides keypad-based operator input, color graphic display, and Ethernet/RS-232 communications for PanelView Plus HMI operation.

Hardware Specifications

Industrial Network and Interface Characteristics

The 2711P-K10C4A2 provides Ethernet and RS-232 communication interfaces for connection to compatible control and operator-interface equipment. The Ethernet interface supports network communication, while the RS-232 interface provides serial communication capability.

The operator input is implemented through a physical keypad with programmable function keys. Individual function keys can be assigned to defined HMI functions for direct operator activation. The 10.4 in color display provides 640 x 480 pixel graphical presentation.

The supplied data identifies two USB ports and a 128 MB logic module. The stated input supply range is 85-264 VAC at 50/60 Hz.

Frequently Asked Questions (FAQ)

Q: What type of operator input does the 2711P-K10C4A2 use?
A: The terminal uses a physical keypad with programmable function keys. Individual keys can be assigned to specific operator-interface functions.

Q: Which communication interfaces are specified for this terminal?
A: The supplied specifications identify Ethernet and RS-232 communication, plus two USB ports.

Q: What display and memory specifications are provided?
A: The terminal has a 10.4 in color display with 640 x 480 pixel resolution and a 128 MB logic module.

Field Installation Guidelines

• Verify that the panel cutout and mounting arrangement are compatible with the PanelView Plus 1000 terminal before installation.
• Confirm that the available supply is within the specified 85-264 VAC input range and is suitable for 50/60 Hz operation.
• Route Ethernet and RS-232 communication cables separately from high-current power conductors where practical to reduce electrical interference.
• Maintain proper cable shielding and grounding practices according to the connected equipment and site electrical standards.
• Provide appropriate strain relief for communication, USB, and power connections.
• Verify connector engagement and cable routing before energizing the terminal.
• Do not apply power until the terminal is securely mounted and all required electrical connections have been inspected.
• Use the specified 2711P-RL10C backlight and 1761-NET-ENI communication cable only where required by the applicable installation configuration.
• Confirm that the installed terminal configuration and connected communication equipment are compatible before placing the HMI into operational service.
