Allen-Bradley 2711P-RP1 PanelView Plus Logic Module
$123.00
$320.00
Description
Allen-Bradley 2711P-RP1 PanelView Plus Logic Module
The Allen-Bradley 2711P-RP1, also cataloged as the 2711P-RP1 logic module, operates as a dedicated hardware component for application runtime execution and memory handling within PanelView Plus HMI terminals. It manages system logic processing, volatile and non-volatile data storage, and terminal-level application loading through integrated RAM and flash memory resources.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 2711P-RP1 |
| Brand | Allen-Bradley |
| Origin | USA |
| Product Type | Logic Module |
| Product Line | PanelView Plus |
| Weight | 2.01 lbs |
| Operating Temp | 0 to 55 deg C |
| Storage Temp | -25 to 70 deg C |
| Humidity | 5 to 95% non-condensing |
| Input Voltage | 24 VDC |
| Power Consumption | 70 W |
| Memory Type | RAM and Flash |
| RAM Capacity | 64 MB |
| Flash Capacity | 64 MB |
| Compatibility | PanelView Plus 700 to 1500 |
| Shock (Operating) | 15 G for 11 ms |
| Shock (Non-operating) | 30 G for 11 ms |
| Altitude | Up to 2000 m |
EtherNet/IP and Backplane Communication Characteristics
The module interfaces with PanelView Plus terminals through an internal backplane bus, supporting deterministic data exchange between the logic module and display interface. Communication timing is governed by fixed backplane bandwidth allocation rather than dynamic polling.
Firmware stored in flash memory is executed directly during boot, while RAM is allocated for runtime application execution and tag processing. Firmware flash compatibility must match the terminal series revision to ensure correct bootloader operation.
Integration with EtherNet/IP networks is handled via the host terminal, where the logic module maintains memory mapping for tag exchange. Data consistency is preserved through cyclic updates managed by the terminal firmware rather than the module itself.
Frequently Asked Questions (FAQ)
Q: Does the 2711P-RP1 support hot-swapping during operation?
A: No. The module is not designed for insertion or removal under power. Power must be removed from the terminal before replacement to avoid backplane damage or data corruption.
Q: How is memory utilized between RAM and flash?
A: Flash memory stores firmware and application files persistently, while RAM is used for runtime execution, temporary variables, and active process data.
Q: What are the compatibility limitations with PanelView terminals?
A: The module is compatible only with PanelView Plus 700 to 1500 series terminals. Firmware revision alignment between terminal and module is required for proper initialization.
Field Installation Guidelines
- Ensure complete removal of 24 VDC input power before installing or removing the module.
- Insert the module firmly into the backplane connector, maintaining even pressure to avoid pin misalignment.
- Verify grounding continuity between the terminal chassis and panel ground to minimize electrical noise.
- Route power and communication cables separately to reduce electromagnetic interference affecting memory operation.
- Maintain adequate spacing for heat dissipation, as the module contributes to internal enclosure thermal load.
