Allen-Bradley 2713P-T6CD1 PanelView Plus 6 600 Series Graphic Terminal
Configured for real-time operator visualization and machine control, the Allen-Bradley 2713P-T6CD1 (2713P-T6CD1 Graphic Terminal) provides touchscreen HMI operation through Ethernet, RS-232, and USB interfaces.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 2713P-T6CD1 |
| Brand | Allen-Bradley / Rockwell Automation |
| Product Line | PanelView Plus 6, PanelView 600 Series |
| Product Type | Color Graphic Operator Interface Terminal |
| Display Type | Color transflective TFT LCD |
| Display Size | 5.7 inches diagonal |
| Display Resolution | 320 x 240 pixels, QVGA |
| Operator Input | Analog resistive touchscreen |
| Input Power / Voltage | 24 VDC nominal; 18-30 VDC operating range |
| Power Consumption | 15 W maximum; 0.63 A at 24 VDC |
| On-Board Memory | 256 MB RAM; 512 MB Flash |
| Expansion Slot | SD card slot |
| Ethernet Interface | 1 x 10/100 Mbps RJ-45 |
| Serial Interface | 1 x RS-232 |
| USB Host Ports | 2 x USB 2.0 |
| USB Device Port | 1 x USB Device |
| Real-Time Clock | Battery-backed internal real-time clock |
| Operating Temp | 0 deg C to 55 deg C |
| Enclosure Rating | NEMA Type 12, 13, 4X, indoor use only; IP66 |
Industrial Control Interface Characteristics
The 2713P-T6CD1 uses a resistive touchscreen for direct operator input on the 5.7-inch QVGA display.
Ethernet provides 10/100 Mbps network communication through an RJ-45 interface for HMI system integration.
The terminal also provides RS-232 connectivity for serial communication with compatible automation equipment and peripheral devices.
Two USB 2.0 Host ports and one USB Device port support local peripheral and service connections.
The 24 VDC supply accepts an 18-30 VDC operating range, with maximum consumption specified at 15 W.
For Allen-Bradley control architectures, communication interface configuration must match the controller protocol and application requirements.
Frequently Asked Questions
Q: What input voltage range does the 2713P-T6CD1 accept?
A: The terminal operates from 18-30 VDC, with 24 VDC specified as the nominal supply voltage.
Q: What physical operator interface does the terminal provide?
A: The terminal uses an analog resistive touchscreen combined with a 5.7-inch color transflective TFT LCD.
Q: Which communication interfaces are physically available?
A: The supplied specifications identify one Ethernet port, one RS-232 port, two USB 2.0 Host ports, and one USB Device port.
Field Installation Guidelines
Mount the terminal within the specified 0 deg C to 55 deg C operating temperature range.
Provide a regulated 24 VDC supply capable of supporting the specified maximum 15 W terminal consumption.
Verify supply polarity and terminal wiring before energizing the unit.
Route communication cables separately from high-current motor, contactor, and variable-frequency-drive conductors where practical.
Use appropriate shield termination practices for shielded communication cables according to the connected network hardware requirements.
Maintain physical clearance around the terminal and avoid obstructing ventilation or service access points.
Confirm that the panel cutout, mounting hardware, enclosure sealing, and environmental protection requirements match the installation design.
Do not expose the indoor-rated terminal to environmental conditions outside its specified enclosure application.
Configure Ethernet, RS-232, and USB connections only with compatible devices and interface requirements.
Verify touchscreen operation, display response, communication status, and power stability after installation.
