Allen-Bradley 6177R-M3PXPDC/B VersaView 5400 Industrial Computer
$123.00
$320.00
Description
Allen-Bradley 6177R-M3PXPDC/B VersaView 5400 Industrial Computer
Configured for industrial HMI execution and visualization data processing in VersaView 5400 automation platforms, the AB 6177R-M3PXPDC/B (6177R-M3PXPDC/B Industrial Computer) provides direct physical/electrical execution for factory computing applications.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 6177R-M3PXPDC/B |
| Brand | Allen-Bradley / Rockwell Automation |
| Origin | USA |
| Operating Temp | 0 deg C to 50 deg C |
| Power Consumption | Not specified in available documentation |
| Product Family | VersaView 5400 Non-Display Industrial Computer |
| Mounting Type | Rack-mount or panel-mount box PC configuration |
| Input Power | 24 VDC (18-32 VDC operating range) |
| Processor Options | Intel Core i3, Intel Core i7, or Celeron processor options depending on configuration |
| System Memory | 8 GB or 16 GB DDR4 RAM expandable configuration |
| Storage | 128 GB to 512 GB industrial-grade SSD options |
| Operating System | Windows 10 IoT Enterprise 64-bit |
| Ethernet Interface | Dual 10/100/1000 Mbps RJ45 Gigabit Ethernet ports |
| USB Interface | 4 x USB 3.0 ports and 2 x USB 2.0 ports |
| Display Interface | 2 x DisplayPort DP++ outputs supporting dual independent monitors |
| Serial Interface | 1 x configurable RS-232 / RS-422 / RS-485 COM port |
| Expansion Interface | PCIe expansion slot support with PCIe x16 / PCIe x4 configuration dependent |
EtherNet/IP Industrial Computing and I/O Integration
The 6177R-M3PXPDC/B supports deterministic Ethernet communication environments through dual Gigabit Ethernet interfaces. The industrial computer architecture enables integration with Allen-Bradley control platforms through network-based HMI, SCADA, and visualization applications.
The VersaView 5400 platform supports industrial control software execution with configurable computing resources. Firmware compatibility, operating system configuration, and installed application requirements determine the supported software environment.
The system provides I/O density scaling through external industrial networks and connected automation devices. PCIe expansion capability allows additional hardware interfaces when required by specific application configurations.
Frequently Asked Questions
Q: Does the 6177R-M3PXPDC/B include an integrated display panel?
A: No. The 6177R-M3PXPDC/B is a non-display industrial computer requiring external display devices through DisplayPort outputs.
Q: What power input is required for the industrial computer?
A: The unit operates from 24 VDC input power with an operating range of 18-32 VDC as specified for this configuration.
Q: Can the system support industrial communication expansion?
A: The computer supports PCIe expansion options and configurable communication interfaces depending on installed hardware configuration.
Field Installation Guidelines
Install the 6177R-M3PXPDC/B in an enclosure or mounting location suitable for industrial computing equipment. Maintain clearance around ventilation areas to prevent thermal accumulation during operation.
Use shielded Ethernet and signal cables where electromagnetic interference may affect communication performance. Connect cable shields according to the grounding practices defined for the installed control cabinet.
Separate DC power wiring from high-voltage switching circuits and motor drive cables. Verify the 24 VDC supply polarity and grounding arrangement before energizing the equipment.
Confirm operating system image, firmware compatibility, and application software requirements before commissioning. Use approved industrial connectors and secure all mounting hardware against vibration exposure.
