DSMB 151 57360001-K | ABB DSMB151 Display Memory and Control Module

Description

The ABB DSMB151 is a display memory and control module engineered for Advant Master systems and ACS600 drives. It delivers reliable memory handling for operator interfaces and supports fast communication with supervisory platforms. Therefore, it helps users maintain stable visualization and control in demanding industrial environments. Each function focuses on real-time responsiveness, and every detail reflects ABB’s long field experience. Moreover, the module integrates smoothly into existing ABB architectures, allowing engineers to upgrade systems without structural changes.

Key Features

• Stable Display Memory Handling: The module manages display buffers with consistent performance, even under heavy load.

• Integrated Control Functions: It supports advanced control tasks in ACS600 drives, including Direct Torque Control.

• Fast Communication: Modbus RTU ensures predictable data exchange with SCADA, DCS, and operator stations.

• Industrial Durability: It operates across wide temperature limits and withstands continuous industrial duty cycles.

• Compact Form Factor: The slim layout enables simple mounting inside dense control panels.

• Proven ABB Reliability: The module reflects ABB’s long-term engineering standards and system compatibility.

Technical Specifications

Dimensions: 235 × 250 × 20 mm
Weight: 0.4 kg
Operating Voltage: 24 V DC
Memory Capacity: 512 KB
Interface: Modbus RTU
Operating Temperature: -25°C to +70°C
Storage Temperature: -40°C to +85°C

Typical Applications

The DSMB151 supports Advant Master operator stations that require stable display refresh. In addition, it serves as a control board in ACS600 drives, where real-time data must stay synchronized. Engineers commonly deploy this module in process plants, utilities, and manufacturing systems that demand durable HMI and control links. For instance, it fits upgrades of legacy ABB installations where continuity and compatibility are critical.

Support & Maintenance

ABB’s modular design enables fast replacement and straightforward diagnostics. Therefore, users reduce downtime while keeping their automation platforms up to date. Routine inspection of connectors and airflow typically ensures long product life, even in harsher zones.

FAQ

Q1: Does the DSMB151 support legacy Advant Master configurations?
Yes, it integrates smoothly with existing Advant Master operator stations and communication structures.

Q2: Can this module operate in high-temperature environments?
Yes, the wide operating range of -25°C to +70°C supports challenging industrial conditions.

Q3: Is the device suitable for ACS600 upgrade projects?
Yes, the module works as a compatible control board within ACS600 drive systems.

Q4: What communication protocol does it use?
It communicates via Modbus RTU for predictable and stable data exchange.
