Emerson EPRO CON021/914-060 Eddy Current Signal Converter
$178.00
$390.00
Description
Overview
The EPRO CON021/914-060 is a high-precision eddy current signal converter designed for monitoring rotating machinery. It provides accurate measurement of shaft displacement, axial position, eccentricity, and speed/key signals. This module is widely used in steam, gas, and hydro turbines, as well as compressors, pumps, and fans.
Compatible with multiple eddy current probes (PR6422, PR6423, PR6424, PR6425, PR6426, PR6453), the converter transforms sensor signals into standardized analog outputs for integration with monitoring and protection systems, ensuring reliable performance in critical machinery applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Function | Eddy current signal conversion: shaft displacement, axial position, eccentricity, speed/key signal monitoring |
| Frequency Range | 0 – 20,000 Hz (-3 dB) |
| Rise Time | < 15 μs |
| Compatible Sensors | PR6422, PR6423, PR6424, PR6425 (requires extended range), PR6426, PR6453 |
| Measuring Range | PR6424: 6.0 mm (Extended Range) |
| Linearity Error | ≤ 1.0% |
| Supply Voltage | -23 V to -32 V (Output -4 V to -20 V) / -21 V to -32 V (Output -2 V to -18 V) |
| Output Signal | Standardized analog signals (configurable) |
| Operating Temperature | -30°C to +100°C |
| Shock & Vibration | 5g @ 60 Hz @ 25°C |
| Protection Class | IP20 |
| Housing Material | LMgSi 0.5 F22 Aluminum Alloy |
| Weight | 120 g |
| Mounting | Panel mount with 4 x M5x20 screws |
| Connections | Self-locking LEMO plug or screw terminal options |
| System Compatibility | MMS 6000 / IMR 6000 racks, hot-swappable installation |
Key Features
-
High-speed response and precise dynamic measurement
-
Broad probe compatibility for flexible applications
-
Industrial-grade interference resistance and environmental durability
-
Compact, lightweight aluminum alloy housing
-
Multiple connection options for system integration
-
Seamless compatibility with MMS 6000 / IMR 6000 monitoring racks
Applications
-
Monitoring of steam, gas, and hydro turbines
-
Rotating machinery such as compressors, pumps, and fans
-
Process control and protection systems, converting sensor data into actionable signals for PLCs and monitoring racks
FAQ
Q: Which probes are supported by this converter?
A: Supports PR6422, PR6423, PR6424, PR6425, PR6426, and PR6453. PR6425 requires an extended range converter.
Q: What mounting options are available?
A: Panel mount using 4 M5 screws, with LEMO plug or screw terminal connections.
Q: What type of output signal does it provide?
A: Standard analog signals. Output range depends on supply voltage: -4 V to -20 V or -2 V to -18 V.
Q: Is this suitable for high-vibration environments?
A: Yes, it has 5g @ 60 Hz shock and vibration resistance, suitable for industrial rotating machinery.
