Emerson VE4031S2T2B1 KJ3201X1-EA1 Redundant Discrete Terminal Block
$178.00
$390.00
Description
Overview
The Emerson VE4031S2T2B1 KJ3201X1-EA1 Redundant Discrete Terminal Block supports DeltaV™ M-series discrete I/O cards. It provides reliable and organized wiring for digital inputs and outputs from field devices. This block offers direct plug-in mounting for easy installation and maintenance in demanding industrial environments.
Technical Specifications
-
Assembly Model: VE4031S2T2B1
-
Terminal Block Model: KJ3201X1-EA1
-
Color Code: Redundant for discrete signals
-
Function: Terminal block for digital input and output
-
Channels Supported: 8 or 16 channels depending on card configuration
-
Signal Type:
-
Digital Input: dry contact or voltage-based
-
Digital Output: 24 VDC high-side switching with DO cards
-
Wiring Interface:
-
Screw-type terminals
-
Clear channel labeling
-
Shielded cable grounding support
-
Mounting:
-
Direct plug-in to M-series I/O cards
-
DIN rail or carrier installation
-
Power Rating: 30 VDC at 1 A per channel, 3 A per card
-
Operating Temperature: –40°C to +70°C
-
Humidity Range: 5% to 95% non-condensing
-
Shock Resistance: 10 g half-sine wave for 11 ms
-
Vibration Resistance: 1 mm peak-to-peak from 2–13.2 Hz, 0.7 g from 13.2–150 Hz
-
Airborne Contaminants: Meets ISA-S71.04–1985 Class G3
