Epro MMS3110/011-000 Dual-Channel Vibration Transmitter
$178.00
$390.00
Description
Product Overview
The MMS3110/011-000 is a dual-channel shaft vibration transmitter from Epro (Emerson MMS 3000 series), developed for continuous condition monitoring and protection of rotating machinery. It processes signals from eddy current proximity probes and converts them into standardized analog outputs for control and protection systems.
It is engineered for turbomachinery environments where stable vibration measurement, fast fault detection, and high system availability are required.
System Design
The unit integrates two fully independent measurement channels within a single housing. Each channel performs separate signal conditioning, linearization, and diagnostic evaluation, enabling parallel monitoring of two vibration points such as bearing positions or shaft axes.
The architecture reduces external instrumentation requirements while improving system reliability and response time.
Redundant 24 V DC power inputs provide continuous operation even in the event of a single power supply failure.
Technical Specifications
Model: MMS3110/011-000
Manufacturer: Epro (Emerson MMS 3000 Series)
Device Type: Dual Channel Shaft Vibration Transmitter
Measurement Principle: Eddy current proximity probe system
Input Channels: 2 independent vibration channels
Supported Sensors: PR6422, PR6423, PR6424, PR6425
Output Signals:
-
2 × analog outputs (0/4–20 mA configurable)
-
Up to 5 configurable relay/function outputs depending on configuration
Power Supply: Dual redundant 24 V DC inputs
Signal Processing: Embedded microcontroller with real-time processing per channel
Diagnostics: Sensor break detection, signal plausibility checks, internal health monitoring
Mounting: Machine-mounted or panel/cabinet installation
Environmental Design: Industrial-grade construction for vibration, heat, and harsh environments
Standards: API 670, VDI 2059
Origin: Germany
Key Features
-
Independent dual-channel vibration measurement
-
High-precision eddy current signal conditioning
-
Integrated diagnostic and fault detection functions
-
Stable industrial analog outputs compatible with PLC and DCS systems
-
Designed for continuous operation in turbomachinery applications
-
Redundant power supply for increased system availability
Application Areas
-
Gas and steam turbines
-
Centrifugal compressors
-
Industrial pump systems
-
Power generation rotating machinery
-
Critical vibration monitoring and protection systems
FAQ
What is the main function of this transmitter?
It converts eddy current probe signals into standardized outputs for vibration monitoring and machinery protection.
Are both channels independent?
Yes, each channel operates independently with separate signal processing and output generation.
Is it suitable for API 670 systems?
Yes, it is fully compliant with API 670 vibration protection requirements.
Does it support redundant power input?
Yes, it supports dual 24 V DC redundant power inputs for higher reliability.
