Foxboro FBM206 P0916CQ 16-Channel Analog Input Module
$177.00
$350.00
Description
Product Description
The Foxboro FBM206 (P0916CQ) is a 16-channel analog input module engineered for the Foxboro I/A Series Distributed Control System (DCS). It accurately captures 4–20 mA DC signals from industrial transmitters, providing precise, isolated measurements of key process variables such as pressure, flow, temperature, and level.
Each input channel is fully isolated, preventing interference between channels and ensuring high immunity to electrical noise. This design guarantees reliable operation even in harsh industrial environments. The module’s architecture supports hot-swapping and field replacement, allowing maintenance without shutting down the control system.
The FBM206 is widely deployed in oil & gas, petrochemical, power generation, water treatment, and other process-critical industries. Its high accuracy, long-term stability, and compatibility with redundant FBM configurations make it a dependable choice for mission-critical analog signal acquisition.
Technical Specifications – FBM206 / P0916CQ
| Parameter | Specification |
|---|---|
| Model | FBM206 |
| Part Number | P0916CQ |
| Module Type | 16-Channel Analog Input |
| Input Signal | 4–20 mA DC |
| Channels | 16 isolated analog inputs |
| Input Impedance | 250 Ω nominal |
| Accuracy | ±0.1% of reading (typical) |
| Resolution | 12-bit or better |
| Isolation | Channel-to-channel and channel-to-system |
| Update Rate | Synchronized with CP scan (~100 ms) |
| Power Consumption | ~3 W |
| Operating Temperature | –20 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity | 5–95% RH, non-condensing |
| EMI/Noise Immunity | Industrial-grade, IEC-compliant |
| Mounting | FBM baseplate / carrier |
| Dimensions | 5.5 × 2.5 × 6 in |
| Weight | 0.45 kg |
| Maintenance | Hot-swappable, field-replaceable |
Key Features
16 fully isolated 4–20 mA input channels
High-accuracy analog measurement with long-term stability
Channel-to-channel isolation for superior noise immunity
Hot-swappable design for continuous plant operation
Rugged construction for demanding industrial conditions
Seamless integration with Foxboro I/A Series DCS
Supports redundant configurations with multiple FBMs
Applications
Pressure transmitters
Flow measurement devices
Temperature transmitters (via 4–20 mA converters)
Level sensing instrumentation
Analyzer output signals
Any industrial 4–20 mA measurement systems
Engineering Advantages
Ensures signal integrity under high EMI environments
Field-replaceable module without system downtime
Redundant configurations enhance system reliability
Compatible with a wide range of analog process instruments
FAQ
Q: How many channels does FBM206 / P0916CQ support?
A: The module provides 16 fully isolated analog input channels.
Q: Can it handle redundant configurations?
A: Yes, it supports redundancy when paired with additional FBM modules.
Q: What is the maximum operating temperature?
A: Standard operation is up to +70 °C.
