Foxboro P0970YG Power Cable

Product Description

The Foxboro P0970YG is a standard 24 VDC power interface for Foxboro I/A Series modules. Unlike proprietary connectors, this module accepts conventional industrial 24 VDC control wiring, allowing flexible installation via the I/A Series baseplate or a DIN‑rail 24 VDC distribution block. The supplied cable must accommodate the module’s electrical load while maintaining robust noise immunity in control cabinets.

This solution is suitable for a variety of installations, including distributed control system (DCS) cabinets, industrial panels, and modular automation setups. It ensures reliable operation of the P0970YG module while maintaining compliance with industrial wiring standards.

Technical Specifications

Electrical Requirements

• Voltage: 24 VDC

• Maximum Module Load: ≤ 8.5 W (~0.35 A)

• Recommended Cable Gauge:

• 18 AWG for long runs

• 20–22 AWG for short cabinet connections

• Conductor: Stranded copper

• Insulation Rating: 300 V, industrial control cable

• Shielding: Recommended for EMI/RFI protection in DCS cabinets

Mechanical Specifications

• Cable Type: 2‑wire (L+ and L–), optional 3‑wire with shield

• Jacket Material: PVC or PUR

• Temperature Rating: –20°C to +80°C typical

Connector & Termination

• No proprietary connector required

• I/A Series Baseplate: Wire lands on screw terminals labeled +24V and 0V

• DIN‑Rail Power Block: Supports ferrules or bare wire under screw terminals

Recommended Cable Options

• Belden 8723, 3106A, 3105A – 18–22 AWG, shielded control cable

• UL‑Listed 18/2 stranded shielded cable, 300 V rating

• Phoenix Contact or Wago pre‑made 24 VDC leads with ferruled ends

Key Features

• Provides 24 VDC power feed to Foxboro I/A Series modules

• Compatible with standard industrial control wiring

• Supports shielded cables for EMI protection

• Flexible mounting via baseplate or DIN‑rail power block

• Simple installation with screw-terminal connections

• Ensures reliable operation in DCS cabinets or industrial panels

Applications

• Power feed for P0970YG and other I/A Series modules

• DCS and PLC cabinet installations

• Industrial control panels with 24 VDC distribution

• Harsh plant-floor environments requiring robust wiring

FAQ

Q: Does the P0970YG require a proprietary power connector?
A: No, it uses standard 24 VDC control wiring connected to the I/A Series baseplate or a DIN‑rail power block.

Q: What cable size is recommended for long runs?
A: 18 AWG shielded stranded copper is preferred for long distances.

Q: Can I use pre‑made leads?
A: Yes, pre‑made 18–20 AWG ferruled cables from Phoenix Contact or Wago are suitable.
