General Electric DS3800HPRB1C1C Mark IV Pulse Rate Input Board
$159.00
$359.00
Description
The GE DS3800HPRB1C1C is a pulse rate input board in the Mark IV DS3800 series, identified for use in GE SPEEDTRONIC control equipment. Its component layout includes a modular connector, retention levers, 12 jumpers, one trimmer resistor, one programmable interrupt controller, multiple programmable interval timer devices, and capacitors. These components support the board's pulse-related control circuitry.
Board Configuration and Function
The board combines configurable jumper links with timing and interrupt-control components. Programmable interval timers provide timing functions, while a programmable interrupt controller manages interrupt requests within the associated electronics. The exact pulse input range, supported frequency, channel count, and timing resolution are not established by the available model-specific information.
The modular connector and retention levers form the board's physical connection and retention arrangement. The 12 jumpers and single trimmer resistor are board-level configuration or adjustment elements; their specific settings and adjustment limits should be confirmed against the applicable board documentation before changing an installed unit.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | DS3800HPRB1C1C |
| Brand | General Electric (GE) |
| Series | Mark IV DS3800 |
| Board Type | Pulse Rate Input Board |
| Connector | Modular connector |
| Retention Mechanism | Retention levers |
| Jumpers | 12 |
| Trimmer Resistor | 1 |
| Programmable Interrupt Controller | 1 |
| Programmable Interval Timers | Multiple |
| Capacitors | Multiple |
| Weight | 0.40 lb |
Frequently Asked Questions
Q: What is the function of the DS3800HPRB1C1C?
A: It is identified as a pulse rate input board for GE Mark IV DS3800 control equipment. Its detailed input specifications and supported pulse signal conditions require confirmation from the applicable technical documentation.
Q: What should be checked before replacing this board?
A: Verify the complete part number, DS3800HPRB1C1C, including all suffix characters, and compare the board's connector arrangement and installed configuration. Do not assume that another DS3800HPRB variant is interchangeable without documented confirmation.
Q: Can the trimmer resistor be adjusted during maintenance?
A: The board includes one trimmer resistor, but its calibration purpose and adjustment range have not been verified for this exact model. Confirm the applicable adjustment procedure and test criteria before making changes.
