Description
The Honeywell 51202971-100, also cataloged as the 51202971 I/O Link Cable, provides a six-drop physical connection for I/O devices associated with the ControlEdge HC900 Controller system. The gray PVC cable uses M12 connectors, 6-inch (152 mm) drop spacing, and supports data transfer rates up to 1 Gbps.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 51202971-100 |
| Brand | Honeywell |
| Product Type | I/O Link Cable |
| System | ControlEdge HC900 |
| Cable Type | Gray drop cable |
| Number of Drops | 6 |
| Drop Pitch | 6 inch (152 mm) |
| Connector Type | M12 |
| Data Transfer Rate | Up to 1 Gbps |
| Cable Material | PVC |
| Label | Yellow label, cable A |
| Environmental Rating | IP67 |
| Environmental Temperature Range | -40 deg C to +85 deg C |
| Operating Temperature | -20 deg C to +80 deg C |
| Available Lengths | 1 m, 2 m, 5 m |
I/O Link Physical Connectivity
The 51202971-100 provides six I/O Link drops from the ControlEdge HC900 controller-side connection to connected I/O devices. The 6-inch (152 mm) pitch establishes the physical spacing between drops. M12 connectors provide the device-side connection interface.
The cable is identified by a yellow label designated as cable A. Its specified transfer capability is up to 1 Gbps. The IP67 environmental rating applies to the specified cable assembly, while the supplied data separately lists an environmental temperature range of -40 deg C to +85 deg C and an operating temperature range of -20 deg C to +80 deg C.
Frequently Asked Questions
Q: How many I/O Link drops are provided by the 51202971-100?
A: The cable assembly provides six drops with a specified 6-inch (152 mm) pitch.
Q: What connector type is specified for the cable?
A: The supplied specification identifies M12 connectors.
Q: What operating temperature should be used for installation planning?
A: The supplied operating temperature specification is -20 deg C to +80 deg C. A separate environmental temperature range of -40 deg C to +85 deg C is also specified and should not be treated as the normal operating range.
Field Installation Guidelines
- Verify that the cable model and yellow cable A identification correspond to the intended ControlEdge HC900 I/O Link connection.
- Route the cable to avoid excessive mechanical stress, sharp bends, crushing, and abrasion.
- Ensure M12 connectors are correctly aligned and fully secured before placing the I/O Link network into service.
- Maintain separation from high-voltage power conductors and high-current switching circuits where practical to reduce electromagnetic interference.
- Use appropriate cable shielding and grounding practices where the installed HC900 system design specifies them.
- Respect the specified -20 deg C to +80 deg C operating temperature range when determining the normal installation environment.
- Confirm that mating connectors and associated field devices provide the required environmental protection when the complete assembly is exposed to moisture or dust.
- Do not exceed the available cable length configuration selected for the installation; supplied lengths are 1 m, 2 m, and 5 m.
Features
We welcome bulk orders and have a minimum order quantity of just one unit.
Upon request, we can provide all necessary documentation, including Certificates of Origin/Conformance and other required export documents.
For items in stock, we aim to deliver within 1-3 days after payment confirmation. Items with specified lead times will be delivered according to the quoted schedule.
We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% due before shipment. For RMB transfers, please contact us if you have an agent in China.
We offer a standard one-year warranty on all new and original items. If you require an extended warranty, please contact us for additional cost details.
Your satisfaction is important to us. If you need to return an item, it must be done within 30 days of the order date. The product must be unused, unopened, and in its original packaging with all accessories included. Refunds are processed within 5-7 business days after we receive the returned item. Please note that shipping and related charges are non-refundable.
