Honeywell FS-BSDOL-04UNI Range-setting Module

Overview

The FS-BSDOL-04UNI is a range-setting module tailored for Honeywell’s SDOL-0424 loop-monitored digital output module. It adjusts current sensing thresholds to prevent false lead-break detection on unused channels. By mounting directly on the I/O backplane's programming connector (Px), it simplifies integration into Honeywell Safety Manager SC systems. This module enhances diagnostic accuracy and supports redundant output configurations for critical safety applications.

Technical Specifications

• Model Number: FS-BSDOL-04UNI

• Product Type: Range-setting module

• Compatible System: Honeywell Safety Manager SC

• Compatible Output Module: SDOL-0424

• Supported Channels: 4 loop-monitored output channels

• Mounting: DIN rail or panel mount, direct Px connector interface

• Range Setting Accuracy: ±0.5%

• Operating Voltage: 24 VDC

• Power Consumption: < 5 W

• Communication Interface: RS-485 (in some variants)

• Redundancy Support: Yes, supports redundant SDOL-0424 modules

• Operating Temperature: −20°C to +70°C

• Storage Temperature: −40°C to +85°C

• Humidity Tolerance: 0–95% RH (non-condensing)

• Protection Rating: IP65

• Dimensions: 120 mm × 60 mm × 40 mm

• Weight: 0.4 kg
