Honeywell MC-TDOD13 Digital Output Module
$209.00
$450.00
Description
Overview
The MC‑TDOD13 is a 16-channel digital output module engineered for Honeywell Series 8, TDC 3000, and Experion PKS distributed control systems. Designed for demanding industrial environments, it delivers precise, isolated digital switching for field devices including relays, solenoids, contactors, pilot lights, and interlock circuits. This module is part of Honeywell’s Enhanced Micro I/O (EMI/O) family, ensuring robust reliability, fault detection, and seamless integration with DCS platforms.
Technical Specifications
General Information
| Feature | Specification |
|---|---|
| Model | MC‑TDOD13 |
| Module Type | Digital Output (DO) |
| System Compatibility | Honeywell TDC 3000, Experion PKS, Series 8 I/O |
| Number of Channels | 16 isolated digital outputs |
| Output Type | Dry-contact or relay-driven (dependent on TA) |
Electrical Characteristics
| Feature | Specification |
|---|---|
| Output Voltage | Typically 24 V DC (field-supplied) |
| Output Current | Up to 2 A per channel |
| Isolation | Channel-to-channel and channel-to-system isolation |
| Switching Mechanism | Solid-state or relay-driven (TA-dependent) |
| Protection | Over-current, short-circuit, and thermal protection |
Performance & Diagnostics
| Feature | Specification |
|---|---|
| Response Time | Fast switching suitable for interlocks and logic control |
| Monitoring | Channel status LEDs, fault detection, health diagnostics |
| Reliability | Continuous operation in 24/7 industrial environments |
Environmental & Mechanical
| Feature | Specification |
|---|---|
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5%–95% non-condensing |
| EMI/EMC | Industrial-grade compliance |
| Mounting | Series 8 / EMI/O chassis with compatible Termination Assembly |
| Weight | Approx. 0.5–0.8 kg (module dependent) |
Functional Highlights
-
16 isolated digital outputs for precise field control
-
High electrical isolation for safety-critical operations
-
Built-in fault detection and channel diagnostics
-
Ideal for shutdown systems, interlocks, sequencing, and logic operations
-
Full integration with Honeywell DCS platforms
Application Scenarios
The MC‑TDOD13 is commonly deployed in chemical plants, oil & gas facilities, power generation, and manufacturing lines where reliable digital output control and interlock functions are required.
FAQ
Q: Can this module handle both solid-state and relay outputs?
A: Yes, the output type depends on the connected Termination Assembly (TA).
Q: What is the maximum load per channel?
A: Each channel supports up to 2 A depending on the TA and connected devices.
Q: Is it suitable for continuous operation in harsh environments?
A: Yes, the MC‑TDOD13 is designed for 24/7 industrial operation with robust protection and diagnostics.
Q: Which Honeywell DCS platforms are supported?
A: Compatible with Series 8, TDC 3000, and Experion PKS systems.
