ProSoft MVI56-MNETC ControlLogix Modbus TCP/IP Client Enhanced Communication Module
$123.00
$320.00
Description
The ProSoft MVI56-MNETC, also cataloged as the MVI56 Modbus TCP/IP Client Enhanced Communication Module, operates as a dedicated hardware component for multi-client Ethernet data exchange within Allen-Bradley ControlLogix backplane platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | MVI56-MNETC |
| Brand | ProSoft Technology |
| Origin | United States |
| Weight | 0.57 lbs |
| Operating Temp | 0 deg C to 60 deg C (32 deg F to 140 deg F) |
| Power Consumption | 800 mA @ 5.1 VDC; 3 mA @ 24 VDC |
| Ethernet Port | 1x RJ45 10/100 Mbps (Auto-sensing, Auto-MDIX) |
| Configuration Port | RJ45 (RS-232 mini-DIN breakout cable included) |
| Backplane Interface | ControlLogix 1756 backplane |
| Supported Protocols | Modbus TCP/IP Client, Modbus TCP/IP Server (diagnostic) |
Protocol Conversion Latencies and Network Performance
The module executes protocol conversion between the deterministic ControlLogix backplane bus and external Ethernet infrastructure. Configured to manage up to 30 simultaneous Modbus TCP/IP client connections, the internal processing engine handles up to 16 customizable command blocks per client connection. Protocol conversion latencies are minimized through backplane I/O messaging and explicit messaging routines, ensuring rapid data throughput when polling field devices, variable frequency drives, and power monitoring hardware without degrading PAC CPU cycle times.
Frequently Asked Questions
Q: How is the backplane current draw distributed across the ControlLogix power supply rails?
A: The module draws 800 mA at 5.1 VDC from the backplane to power its internal processing logic and network interface chips, while consuming a minimal 3 mA at 24 VDC for auxiliary onboard sensing circuits.
Q: Can the MVI56-MNETC module be inserted or removed while the ControlLogix chassis is powered?
A: Yes, the module supports Removal and Insertion Under Power (RIUP) capability within standard 1756 chassis environments, provided that safe industrial electrical practices and hazardous location requirements are observed.
Q: What port options are available for uploading configuration files from ProSoft Configuration Builder?
A: Configuration files can be downloaded directly over the standard RJ45 10/100 Mbps Ethernet port or locally through the dedicated mini-DIN serial configuration breakout port.
Field Installation Guidelines
- Ensure the ControlLogix chassis ground bus is connected to the central protective earth (PE) with a minimum 8 AWG copper wire.
- Align the module with the target slot card guides in the 1756 chassis and press firmly until the top and bottom retaining tabs latch securely onto the backplane.
- Terminate Ethernet connections using shielded twisted-pair (STP) Category 5e or Category 6 cabling to mitigate industrial high-frequency electromagnetic interference.
- Route serial configuration cable lines separately from high-voltage AC lines and motor drive outputs, maintaining at least 20 cm separation.
