ProSoft PLX31-EIP-MBS EtherNet/IP Gateway Module

Product Description

The PLX31-EIP-MBS communication module is an industrial protocol gateway developed by ProSoft Technology for integrating EtherNet/IP controllers with Modbus serial field devices. It enables reliable bidirectional communication between Rockwell Automation PLC platforms and Modbus RTU or ASCII networks in mixed-protocol automation environments.

Designed as a standalone DIN-rail device, the module supports flexible deployment in control cabinets, SCADA systems, OEM machinery, and retrofit modernization projects. The gateway combines EtherNet/IP Scanner and Adapter functionality with configurable Modbus Master or Slave operation, simplifying communication between modern Ethernet architectures and legacy serial equipment.

The compact industrial housing, extended operating temperature range, and diagnostic capabilities make the PLX31-EIP-MBS suitable for continuous operation in demanding industrial facilities.

Technical Specifications

Communication Functions

The gateway provides protocol conversion between EtherNet/IP and Modbus serial devices without requiring custom PLC programming. It supports deterministic polling structures and configurable data exchange tables for stable communication performance.

Supported device integration includes:

• Variable frequency drives

• Power meters and analyzers

• Remote I/O stations

• Temperature controllers

• Process instrumentation

• Legacy Modbus RTU equipment

Configuration and Diagnostics

Configuration is performed using ProSoft Configuration Builder software through Ethernet connectivity. Integrated diagnostic tools help maintenance personnel monitor communication quality and troubleshoot network issues.

Available diagnostics include:

• Modbus exception reporting

• Packet statistics

• CIP connection monitoring

• Serial communication status

• Ethernet link diagnostics

Key Features

• EtherNet/IP to Modbus RTU/ASCII protocol conversion

• Simultaneous industrial Ethernet and serial communication

• Flexible Master and Slave operating modes

• Compatible with ControlLogix, CompactLogix, and Micro800 controllers

• Industrial DIN-rail installation

• High-speed data mapping for process applications

• Built-in communication diagnostics

• Designed for continuous industrial operation

Typical Applications

The PLX31-EIP-MBS gateway is commonly installed in systems where Ethernet-based PLC platforms must communicate with existing Modbus serial infrastructure.

Typical installations include:

• Water and wastewater facilities

• Oil and gas processing

• Manufacturing production lines

• Power generation systems

• Building automation systems

• Industrial retrofit projects

FAQ

Can the PLX31-EIP-MBS operate as both Modbus Master and Slave?

Yes. The module supports configurable Master or Slave operation depending on the application requirements.

Which Allen-Bradley PLC families are compatible?

The gateway is commonly used with ControlLogix, CompactLogix, and Micro800 controllers through EtherNet/IP communication.

Does the module support both RS-232 and RS-485?

Yes. The serial interface can be configured for either RS-232 or RS-485 communication standards.

Is the gateway suitable for industrial environments?

Yes. The unit is designed for industrial control panels and supports extended temperature operation, DIN-rail mounting, and Class I Division 2 certification.
