Schneider TSXAEZ802 Analog Input Module
    Schneider TSXAEZ802 Analog Input Module

    Schneider TSXAEZ802 Analog Input Module

    • 1000 In stock

    • Manufacturer: Schneider

    • Product No.: TSXAEZ802

    • Condition： In stock

    • Product Type: Analog Input Module

    • Product Origin: France

    • Payment:T/T, Western Union

    • Weight: 200g

    • Shipping port: Xiamen

    • Warranty: 12 months

    {"id":42002028527706,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"TSXAEZ802","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Schneider TSXAEZ802 Analog Input Module","public_title":null,"options":["Default Title"],"price":15100,"weight":200,"compare_at_price":32600,"inventory_management":"shopify","barcode":"France","requires_selling_plan":false,"selling_plan_allocations":[]}

    Description

    Overview

    The Schneider TSXAEZ802 is an analog input module designed for the Modicon TSX Micro automation platform. It features 8 input channels with 12-bit resolution. This module suits industrial control applications requiring precise analog signal processing. It supports input currents of 0...20 mA and 4...20 mA ranges. The device operates with a low temperature drift and offers robust electrical isolation for safety and noise immunity.

    Technical Specifications

    • Model Number: TSXAEZ802

    • Series: Modicon TSX Micro

    • Manufacturer: Schneider Electric

    • Type: Analog Input Module

    • Number of Inputs: 8 channels

    • Analog Input Type: 0...20 mA, 4...20 mA

    • Resolution: 12-bit analog-to-digital conversion

    • Acquisition Period: 32 ms

    • Temperature Drift: 0.054% per 10 °C

    • Input Impedance: 250 Ω

    • Current Consumption: 60 mA

    • Isolation Voltage: 1000 V AC

    • Weight: 0.2 kg

    Features

    We welcome bulk orders and have a minimum order quantity of just one unit.

    Upon request, we can provide all necessary documentation, including Certificates of Origin/Conformance and other required export documents.

    For items in stock, we aim to deliver within 1-3 days after payment confirmation. Items with specified lead times will be delivered according to the quoted schedule.

    We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% due before shipment. For RMB transfers, please contact us if you have an agent in China.

    We offer a standard one-year warranty on all new and original items. If you require an extended warranty, please contact us for additional cost details.

    Your satisfaction is important to us. If you need to return an item, it must be done within 30 days of the order date. The product must be unused, unopened, and in its original packaging with all accessories included. Refunds are processed within 5-7 business days after we receive the returned item. Please note that shipping and related charges are non-refundable.
