Siemens 2021828-001 Power Entry and Control Module
$209.00
$530.00
Description
Product Description
The 2021828-001 PECM-2 is a precision power entry and control module designed for Siemens Maxum Gas Chromatographs (GC). It ensures stable power delivery, manages subsystem control, and provides diagnostic monitoring for critical components such as column ovens, temperature circuits, and solenoid valves. Built for reliability, this module integrates advanced monitoring via I²C interfaces to support preventive maintenance and uninterrupted operation.
Technical Specifications
| Attribute | Specification |
|---|---|
| Module Type | Power Entry and Control Module (PECM-2) |
| Input Voltage | 100–240 VAC |
| Output Voltage | 24 V DC |
| Max Output Current | 10 A |
| Key Functions | Power distribution, SSR control, purge monitoring, temperature control |
| Diagnostics | Monitors power status, SSR signals, purge operations, and temperature via I²C |
| Compatibility | Siemens Maxum GC subsystems: ovens, temperature circuits, solenoid valves |
| Weight | 650 g |
| Mounting | Integrated into Maxum GC system chassis |
| Operating Environment | Continuous operation in analytical labs |
Key Features
-
Stable DC Power: Converts and regulates incoming AC power to supply critical GC subsystems
-
Subsystem Management: Controls oven heating, solenoid valves, and temperature circuits
-
Integrated Diagnostics: Supports predictive maintenance via built-in I²C monitoring
-
Reliable Operation: Designed for high-uptime analytical instrumentation
-
Compact & Modular: Lightweight design allows seamless installation in Maxum GC systems
Applications
Ideal for analytical laboratories using Siemens Maxum GC systems, where precise temperature management and stable subsystem power are required. Critical for ensuring consistent chromatographic performance.
Similar Model Comparison
-
2021828-002 PECM-3: Supports higher current outputs for enhanced GC subsystems
-
2021830-001 PECM-Lite: Lightweight module for limited functionality setups
FAQ
Q: Can the PECM-2 handle high-power ovens?
A: Yes, it supports oven circuits with regulated 24 V DC outputs up to 10 A.
Q: Is installation user-serviceable?
A: Replacement should be performed by trained technicians to avoid GC performance issues.
Q: Does it include diagnostics?
A: Yes, built-in monitoring tracks power, SSR signals, purge cycles, and temperature.
Features
Minimum Order Quantity (MOQ)
We welcome bulk orders and have a minimum order quantity of just one unit.
Certificates and Documentation
Upon request, we can provide all necessary documentation, including Certificates of Origin/Conformance and other required export documents.
Delivery Time
For items in stock, we aim to deliver within 1-3 days after payment confirmation. Items with specified lead times will be delivered according to the quoted schedule.
Payment Methods
We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% due before shipment. For RMB transfers, please contact us if you have an agent in China.
Warranty
We offer a standard one-year warranty on all new and original items. If you require an extended warranty, please contact us for additional cost details.
Refund and Return Policy
Your satisfaction is important to us. If you need to return an item, it must be done within 30 days of the order date. The product must be unused, unopened, and in its original packaging with all accessories included. Refunds are processed within 5-7 business days after we receive the returned item. Please note that shipping and related charges are non-refundable.
