Siemens 6ES7153-2BA02-0XB0 ET 200M Interface Module
$209.00
$530.00
Description
Product Description
The 6ES7153-2BA02-0XB0 from Siemens AG is a high-performance interface module (IM 153-2 DP High Feature) for the SIMATIC ET 200M distributed I/O system. Designed for advanced PROFIBUS DP connectivity, it supports integration of up to 12 S7-300 modules with redundancy, precise time stamping, and isochronous operation for high-speed and synchronized automation tasks.
This module enables reliable data exchange between ET 200M racks and central control systems, facilitating process automation, factory automation, and motion control applications. Its compact form factor and industrial-grade design ensure robust performance in demanding environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 6ES7153-2BA02-0XB0 |
| Product Type | ET 200M Interface Module (IM 153-2 DP High Feature) |
| System Platform | SIMATIC ET 200M |
| Supply Voltage | 24 V DC (20.4–28.8 V) |
| Maximum Current Consumption | 600 mA |
| Inrush Current | 3 A typical |
| Power Loss | 3–5.5 W typical |
| Mains Buffering | 5 ms stored energy |
| Backplane Output Voltage | 5 V DC |
| Backplane Output Current | Max. 1.5 A |
| Modules Supported | Up to 12 S7-300 modules per station |
| Redundancy | Supported |
| Time Stamping | Yes, suitable for isochronous mode |
| Special Features | Slave initiative for Drive ES and Switch ES, extended HART secondary variable support, operation of 64-channel modules (32 signals per slot) |
| Vendor ID | 801Eh |
| Dimensions | 11.7 × 4 × 12.5 cm |
| Net Weight | 0.36 kg |
| Country of Origin | Germany |
| Compliance | WEEE, RoHS, REACH |
| Lifecycle Status | End of Product Life (available as spare part) |
Key Functional Features
-
High Feature Version: Provides redundancy and time stamping beyond standard IM modules.
-
Isochronous Mode: Supports precise synchronization for motion control applications.
-
Extended HART Support: Handles secondary variables from smart instrumentation.
-
Scalability: Connect up to 12 S7-300 modules including high-density 64-channel I/O modules.
-
Reliability: Robust power buffering ensures continuous operation in industrial environments.
-
Compact Form Factor: Space-efficient design suitable for ET 200M rack integration.
Application Scenarios
The 6ES7153-2BA02-0XB0 is ideal for:
-
Distributed I/O systems in process and factory automation
-
Motion control and synchronized drive systems
-
Industrial applications requiring high-speed data acquisition and redundancy
-
Upgrading or expanding existing ET 200M installations
Installation and Practical Notes
Ensure compatibility with your PROFIBUS DP network and ET 200M rack layout. The module is typically used in systems where redundancy, precise time stamping, and high-speed isochronous operation are critical.
Although replaced in Siemens’ catalog by 6ES7153-2BA10-0XB0, the 6ES7153-2BA02-0XB0 remains widely available as a spare part.
