Yokogawa ACM12 RS422/485 Communication Module
    Yokogawa ACM12 RS422/485 Communication Module

    Yokogawa ACM12 RS422/485 Communication Module

    • 1000 In stock

    • Manufacturer: Yokogawa

    • Product No.: ACM12 RS422/485

    • Condition： In stock

    • Product Type: Communication Module

    • Product Origin: Japan

    • Payment:T/T, Western Union

    • Weight: 1200g

    • Shipping port: Xiamen

    • Warranty: 12 months

    {"id":41973235384410,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"ACM12 RS422\/485","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Yokogawa ACM12 RS422\/485 Communication Module","public_title":null,"options":["Default Title"],"price":14800,"weight":1200,"compare_at_price":37800,"inventory_management":"shopify","barcode":"Japan","requires_selling_plan":false,"selling_plan_allocations":[]}

    Description

    Overview

    The Yokogawa ACM12 is a compact RS-422/RS-485 communication module designed for industrial automation. It ensures reliable data transfer in harsh environments. Engineers prefer it for process control systems due to its long-distance capability and flexible settings. It installs easily in the communication module nest and supports multiple communication modes.

    Technical Specifications

    • Product Type: RS-422/RS-485 Communication Module

    • Manufacturer: Yokogawa

    • Model Number: ACM12

    • Interface: RS-422 or RS-485 (1 port)

    • Connection Type: Point-to-point or multipoint

    • Communication Mode: Half-duplex

    • Synchronization: Start-stop synchronization

    • Communication Speed: 1200 / 2400 / 4800 / 9600 / 19200 bps

    • Transmission Code: ASCII or Binary

    • Character Length: 7 or 8 bits

    • Stop Bit Length: 1 or 2 bits

    • Parity Check: None, Odd, or Even

    • Signal Reception Delay: 1 ms after transmission

    • Max Transmission Distance: 1200 meters

    • Installation Method: Mounted in Communication Module Nest

    • Wiring Options: 3-pair shielded cable or AKB161 (max. 100 meters)

    • Connection Terminal: 6 poles with M4 screws

    • Power Requirement: 1 A at 5.0 V DC

    Features

    We welcome bulk orders and have a minimum order quantity of just one unit.

    Upon request, we can provide all necessary documentation, including Certificates of Origin/Conformance and other required export documents.

    For items in stock, we aim to deliver within 1-3 days after payment confirmation. Items with specified lead times will be delivered according to the quoted schedule.

    We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% due before shipment. For RMB transfers, please contact us if you have an agent in China.

    We offer a standard one-year warranty on all new and original items. If you require an extended warranty, please contact us for additional cost details.

    Your satisfaction is important to us. If you need to return an item, it must be done within 30 days of the order date. The product must be unused, unopened, and in its original packaging with all accessories included. Refunds are processed within 5-7 business days after we receive the returned item. Please note that shipping and related charges are non-refundable.
