GE IC660BBD101 Genius I/O Block

Overview

The GE IC660BBD101 is a Genius I/O Block designed for industrial automation. It connects discrete sensors and actuators to a communication bus efficiently. Emerson Automation now maintains this module, originally manufactured by GE Fanuc. Notably, all eight circuits are configurable as either inputs or outputs.

Technical Specifications

• Model Number: IC660BBD101

• Product Type: Genius I/O Block, 8-point discrete

• Series: Genius I/O

• I/O Type: 115VAC Low-Leakage Discrete I/O

• Number of Circuits: 8, each independently configurable

• Operating Voltage: 93–132 VAC, nominal 115 VAC

• Frequency: 47–63 Hz

• Load Current (Output): Up to 2 Amps per circuit; maximum 15 Amps total

• Input Response Time: 2 ms plus selectable filter time of 10–100 ms

• Output Response Time: Zero-crossing for precise switching

• Input Filter Time: Configurable from 10 ms to 100 ms

• Output Feedback: Provides voltage monitoring per circuit

• Pulse Testing: Supports output diagnostics

• Power-Up Defaults: Outputs hold last state or revert to default

• Electronic Fusing: Trips in 5 ms if current exceeds 30A; two cycles if above 20A

• Diagnostics: Detects overtemperature, overload, open wire, no-load, and failed switch

• Fault Reporting: Configurable individually per circuit

• LED Indicators: Show Unit OK, I/O Enabled, and per-circuit status

• Isolation Voltage: 1500V block-to-block for one minute

• Heat Dissipation: 16W (inputs); 43.5W max (outputs at 2A)

• Standby Power: 8.5W when all I/O are off

• Dimensions (HxWxD): 8.83" × 3.34" × 3.91" (22.44 × 8.48 × 9.93 cm)

• Weight: 4 lbs
