Triconex HFE1600-24 Power Supply Module

Overview

The HFE1600-24 by TDK-Lambda is a high-efficiency AC-DC front-end power supply. It delivers 1608W at 24VDC and suits demanding industrial and telecom applications. The 1U rack-mount design supports remote monitoring, redundancy, and parallel operation for scalable power systems.

Technical Specifications

Input Characteristics

• AC Input Voltage: Accepts 85–265 VAC (single-phase)

• Input Frequency: Operates from 47–63 Hz

• Power Factor: Exceeds 0.98 at full load (meets EN61000-3-2)

• DC Input Capability: Supports DC input (range not specified)

Output Characteristics

• Rated Output Voltage: Provides 24 VDC

• Adjustable Range: Allows 19.2–29 VDC

• Output Current: Supplies up to 67 A

• Maximum Output Power: Delivers 1608 W

• Efficiency: Typically achieves 90%

• Ripple & Noise: Maintains 240 mVp-p (typically 120 mVp-p)

• Line Regulation: Regulates within 60 mV

• Load Regulation: Maintains within 120 mV

Protection Features

• Overcurrent Protection: Activates at 105–120% of rated current

• Overvoltage Protection: Engages at 110% (reset via AC cycle or remote switch)

• Hold-up Time: Exceeds 10 ms at 80% load (100/230 VAC input)

Isolation Ratings

• Input to Output: 3 kVAC

• Input to Ground: 2 kVAC

• Output to Ground: 500 VAC

Operating Temperature: -10°C to +70°C

Storage Temperature: -30°C to +85°C

Dimensions: 85 × 41 × 300 mm

Weight: 1.55 kg
