Yokogawa ADV551-P63 Digital Output Module

Overview

The ADV551-P63 is a 32-channel digital output module designed for CENTUM VP and ProSafe-RS control systems. It provides current-sinking transistor outputs to control external devices such as relays, solenoids, and indicator lamps. This module suits high-reliability industrial automation applications and supports dual-redundant configurations to ensure fault tolerance and system reliability.

Technical Specifications

• Model: ADV551-P63

• Type: Digital Output Module

• Number of Output Channels: 32 isolated channels

• Rated Applied Voltage: 24 V DC

• Output Format: Current sink

• Maximum Load Current: 100 mA per channel (at 26.4 V DC)

• Load Voltage Range: 20.4 to 26.4 V DC

• Output ON Voltage (max): 2 V DC

• Leakage Current: Typically low, designed for minimal leakage

• Response Time: ≤ 40 ms overall

• Status Output Response Time: ≤ 3 ms

• Mixed Status and Pulse Output Response Time: ≤ 10 ms

• Pulse Width Range: 8 ms to 7200 s

• Pulse Width Resolution: 8 ms (plus max 1 ms ON/OFF delay)

• Dual Redundancy Support: Yes

• Withstanding Voltage:

• Between output signal and system: 2 kV AC for 1 minute

• Between commons: 500 V AC for 1 minute per 16 channels

• Operating Temperature: -20 to 70 °C

• Weight: 0.2 kg

• Installation: Mounted in system rack; compatible with Yokogawa baseboards
