A New Step Forward for Industrial Connectivity
As industrial automation continues to evolve toward decentralized architectures, the demand for smarter and more efficient connectivity solutions is increasing rapidly. Traditional installations often require separate cables for power and communication, creating additional complexity during system design, installation, and maintenance.
binder's B23 hybrid connector addresses these challenges by integrating both power transmission and data communication into a single connector interface. This approach aligns with the growing adoption of One Cable Automation (OCA), where fewer cables translate directly into cleaner system layouts and lower installation costs.
Meeting the Demands of Modern Automation
Manufacturers today are under pressure to build more flexible and scalable production systems. Robotics, servo-driven machinery, and modular manufacturing platforms all require reliable power delivery alongside high-speed communication.
The B23 connector has been engineered specifically for these environments. By combining electrical power and Ethernet-based communication in one connection point, it helps simplify machine integration while maintaining dependable operational performance.
From my perspective as an automation engineer, reducing the number of physical connections is more than a convenience—it significantly improves system reliability by minimizing potential wiring errors, connector failures, and maintenance challenges throughout the equipment lifecycle.
Supporting the Shift Toward Decentralized Control
The industrial sector is steadily moving away from centralized control cabinet designs toward distributed intelligence located directly on machines and production equipment.
This trend creates new requirements for field-level connectivity. Connectors must withstand demanding industrial conditions while delivering both power and communication without compromising performance.
The B23 is well-positioned for these applications, supporting decentralized automation architectures commonly found in:
-
Smart manufacturing systems
-
Distributed I/O networks
-
Robotic cells
-
Automated assembly lines
-
Flexible production environments
Its ability to consolidate multiple functions into one connection helps simplify machine design and supports modular expansion strategies.
Key Technical Specifications
The B23 hybrid connector combines compact dimensions with industrial-grade electrical and communication capabilities.
Key specifications include:
-
One Cable Automation design
-
Power transmission up to 28 A
-
Voltage rating up to 630 V
-
Shielded Cat5 Ethernet/EtherCAT communication
-
Data rates up to 100 Mbit/s
-
Bayonet quick-locking mechanism
-
Screw-clamp field termination
-
Compliance with IEC 61076-2-118 standards
-
Manufacturer-independent interoperability
These specifications make the connector suitable for applications requiring both robust power delivery and reliable industrial networking.
Installation Efficiency as a Core Design Principle
One of the most practical advantages of the B23 is its focus on field installation efficiency.
The connector utilizes screw-clamp termination technology, allowing technicians to assemble and terminate connections without specialized crimping equipment. This simplifies onsite deployment and reduces installation costs.
Additionally, the bayonet locking system enables quick and secure mating while reducing assembly time compared to traditional threaded solutions.
In large-scale machine installations where hundreds of connections may be required, even small reductions in assembly time can deliver significant labor savings.
Engineering Challenges Behind the Design
Developing a hybrid connector capable of carrying both high electrical loads and high-quality communication signals is far from straightforward.
Engineers must address several critical challenges:
-
High-current power transmission
-
High-voltage insulation requirements
-
Electromagnetic compatibility (EMC)
-
Signal integrity protection
-
Limited installation space
Successfully integrating these requirements into a compact, field-attachable connector demonstrates the increasing sophistication of modern industrial connectivity solutions.
Ideal Applications for the B23 Connector
The B23 connector is particularly suited for automation environments where space savings, simplified installation, and reliable communication are essential.
Typical applications include:
-
Servo motor systems
-
Motion control platforms
-
Industrial drives
-
Robotics equipment
-
Decentralized automation architectures
-
Modular machine designs
-
Flexible manufacturing systems
-
Smart factory installations
These sectors continue to push for greater efficiency and reduced system complexity, making hybrid connectivity an increasingly attractive solution.
Flexible Product Variants for System Integration
binder offers multiple B23 configurations to support various implementation requirements.
Available options include:
-
Field-attachable connector versions
-
Panel-mount connectors
-
Single-wire termination variants
-
Through-hole technology (THT) contact versions
This flexibility enables machine builders and OEMs to standardize on a single connector platform across different areas of their equipment designs.
Industry Perspective: Why Hybrid Connectors Matter
Hybrid connectors represent an important evolution in industrial automation infrastructure. As factories become more connected and machine architectures become increasingly modular, reducing wiring complexity is no longer simply a design preference—it is becoming a competitive necessity.
The B23 demonstrates how connector technology is adapting to support Industry 4.0 objectives by enabling simpler installation, faster commissioning, improved maintainability, and greater system scalability.
Looking ahead, I believe hybrid connectivity solutions like the B23 will play a growing role in machine design, particularly in robotics, motion control, and decentralized automation systems where efficiency, flexibility, and reliability remain top priorities.
