Bently Nevada 167699-01 HMI Operator Interface Touch Screen Module

Overview

The Bently Nevada 167699-01 is an industrial-grade Human-Machine Interface (HMI) designed for machinery monitoring systems. Featuring a high-contrast touch screen, it allows operators to view critical machine parameters in real time, including vibration, shaft position, and other operational metrics. The interface enables intuitive navigation, system configuration, and diagnostics, ensuring reliable protection for turbines, compressors, pumps, and other rotating equipment.

Technical Specifications

Key Features

• High-contrast touch screen for simplified navigation and configuration

• Real-time display of vibration, shaft position, and machine health parameters

• Configurable outputs for alarms and protective actions

• Ethernet and RS485 interfaces for easy system integration

• Rugged industrial design for extreme environmental conditions

• Intuitive interface reduces operator training time

Typical Applications

• Power Generation: Turbine monitoring and operator diagnostics

• Oil & Gas: Compressor and pump monitoring with real-time operator feedback

• Chemical Industry: Continuous monitoring of rotating machinery in process plants

FAQ / Common Questions

Q: Which communication interfaces does this module support?
A: It supports Ethernet, RS485, and system bus interfaces for seamless integration with Bently Nevada monitoring systems.

Q: What is the operating temperature range?
A: –40 °C to +70 °C, suitable for most industrial environments.

Q: Can this module be rack-mounted?
A: Yes, it supports both panel and rack mounting.

Q: How does the 167699-01 compare to other Bently Nevada HMI modules?
A: It offers a high-contrast touch screen, flexible input/output configuration, and rugged design, optimized for harsh industrial environments.
