GE IC694TBB032 IC694TBB032C Terminal Block

Product Overview

The GE IC694TBB032 is a high-density, box-style terminal block designed for PACSystems RX3i automation platforms. It provides a secure interface between analog and digital I/O modules and field devices. Moreover, its compact design reduces panel space while ensuring reliable, vibration-resistant connections. This terminal block is ideal for industrial environments, including manufacturing, process control, and energy applications, where consistent and organized wiring is critical.

Key Features and Benefits

• High-Density Design: Supports 36 IEC-style terminals, maximizing connection capacity in a compact footprint.

• Reliable Electrical Connections: Provides secure clamping for both solid and stranded wires, minimizing maintenance issues.

• Flexible Wire Accommodation: Accepts wire sizes from #14–26 AWG, suitable for a wide range of I/O modules.

• Installation Versatility: Can be mounted on DIN rails or directly on panels, simplifying integration into existing systems.

• Durable Construction: Engineered for vibration resistance and industrial-grade reliability, ensuring long-term performance.

• Time-Saving Maintenance: Box-style layout simplifies troubleshooting and module replacement, reducing downtime.

Technical Specifications

• Model Number: IC694TBB032

• Product Type: Box-Style High-Density Terminal Block

• System Compatibility: GE PACSystems RX3i

• Terminal Count: 36 IEC-style terminals

• Wire Size Range: #14–26 AWG (solid or stranded)

• Tightening Torque: 7 lb-in

• Mounting Style: DIN rail or panel mount

• Application: Field wiring for analog and digital I/O modules

• Weight: 0.31 lbs

Typical Applications

• Industrial process control systems requiring reliable signal termination

• Energy and power distribution monitoring setups

• Manufacturing automation with high-density I/O requirements

• Integration with PACSystems RX3i modules for compact and organized wiring

FAQ

Q1: Can the IC694TBB032 handle both analog and digital signals?
A1: Yes, it is designed to terminate both analog and digital I/O signals reliably.

Q2: What wire sizes does this terminal block support?
A2: It supports solid or stranded wires from #14–26 AWG.

Q3: How is this terminal block mounted?
A3: It supports DIN rail or direct panel mounting for flexible installation.

Q4: Is it suitable for high-vibration environments?
A4: Yes, it features secure clamping mechanisms for vibration-resistant performance.

Q5: Can it be used with older Series 90-30 PLC modules?
A5: Yes, it is compatible with equivalent Series 90-30 modules for smooth upgrades.
