GE IC695CPE305LT CPU Module

Overview

The GE IC695CPE305LT is a rugged CPU module designed for harsh industrial environments. It offers high-speed processing, wide protocol support, and extended temperature operation. This makes it ideal for mission-critical applications in energy, transportation, and manufacturing. Its aluminum housing and industrial certifications ensure reliable performance under extreme conditions. Moreover, its flexible programming support enhances control system development.

Technical Specifications

• Model Number: IC695CPE305LT

• Processor: 1.3 GHz Intel Atom Dual-Core

• Memory: 1 GB RAM / 2 GB Flash

• User Memory: 5 MB RAM + 5 MB non-volatile Flash

• I/O Capacity: Supports up to 256 local/remote modules

• Backplane Interface: PCIe, 100 Mbps

• Communication Ports:

• 2× Gigabit Ethernet

• 1× RS-232/485

• 1× USB

• Supported Protocols:

• Modbus TCP/IP

• EtherNet/IP

• Profinet IRT

• OPC UA

• Programming Languages:

• Ladder Diagram

• Structured Text

• Function Block Diagram

• C

• Operating Temperature: –40°C to +85°C (extended range)

• Power Supply: 24 VDC (range: 18–32 V)

• Real-Time Clock: IC690ACC001 battery, 5-year lifespan

• Energy Pack Support: Compatible with IC695ACC400 (for battery-less memory retention)

• Vibration Resistance: 5g, 10–500 Hz (IEC 60068-2-64)

• Housing: IP52-rated aluminum chassis

• Certifications:

• IEC 61508 SIL 2

• ATEX Zone 2

• IECEx

• UL Class I Div 2

• Weight: 0.99 lbs
